Dismountable Cutter Suction Dredger
- Tianjin
- T/T Money Gram
You May Like
Product Details
| Condition | New | Type | Cutter Suction Dredger | |
| Place of Origin | Shandong, China | Brand Name | Yongsheng | |
| Model Number | CSD-350 |
Product Description
Specifications
1. Total length: 37m2. Main power: 1000KW diesel
3. Pump model: 16/14G-GH
4. Dredging depth: 14-16m
The CSD350 Dredger Specification
==================================================================================================
1. GENERAL
No. | Item | Specification |
1 | Total Length (with ladder raised) approx | 35m |
2 | Length over pontoons | 25.00m |
3 | Breadth | 7.2m |
4 | Depth | 1.90m |
5 | Main pontoon | 18.00m × 3.50m × 1.90m |
6 | Side pontoon | 25.00m × 1.850m × 1.90m |
7 | Mean draught with full bunkers approx | 1.3m |
8 | Maximum standard dredging depth | 15.00m |
9 | Dredge pump water flow capacity | 3000m3/h |
10 | Standard discharge distance | 1500m |
11 | Cut Width @ Maximum digging depth | 35m |
12 | Cut Width @ Minimum digging depth | 44m |
2. Marine Diesel Engine to drive dredger pump
Item | Main Diesel Engine |
Manufacturers | JICHAI ENGINE |
Model | 8190ZLCZ-R |
Continuous Power | 720kw@1450rpm |
Amount | 1 Set |
Marine Diesel Engine to drive hydraulic system
Item | Main Diesel Engine |
Manufacturers | WEICHAI |
Model | ZCW-6160 |
Continuous Power | 270kw@1000pm |
Amount | 1 Set |
3. Dredge Pump
Item | Parameters | Note |
Made | Warman Technology, Australia | SHIJIAZHUANG PUMP GROUP |
Type | 350G-H | Professional Dredge Pump |
Capacity | 3000m3/h |
|
Head | 65 m |
|
Speed | 400—550 r/min |
|
Efficiency | 74—78% |
|
NpSHr | small than 4.5 m |
|
Pump Suction Diameter | 400 mm |
|
Pump discharge Diameter | 350 mm |
|
Max.Diameter of Flowed Partice | 201 mm |
|
Solid Capacity | 450m³/h | Count 15% solid |
