Yongsheng Dredging Machinery has 20 years professional manufacturing experience in dredging ,and we have many models and sizes of dredgers.And our products had been sold to 33 countries and regions, every product is specialized produced according to clients' special demand.
we are into this business for 20 years and now we have up to 130,000 M3 workshop and more than 100 engineers and skillfull staff ,we also obtained advanced technology from Germany,America, Holland. we gained ISO9001 Internationl Quality System Certificate , Ship Inspection Certificate of ZC & CCS, besides, we also have Europe CE Certificate.
The CSD350 Dredger Specification
==================================================================================================
1. GENERAL
No. |
Item |
Specification |
1 |
Total Length (with ladder raised) approx |
35m |
2 |
Length over pontoons |
25.00m |
3 |
Breadth |
7.2m |
4 |
Depth |
1.90m |
5 |
Main pontoon |
18.00m × 3.50m × 1.90m |
6 |
Side pontoon |
25.00m × 1.850m × 1.90m |
7 |
Mean draught with full bunkers approx |
1.3m |
8 |
Maximum standard dredging depth |
15.00m |
9 |
Dredge pump water flow capacity |
3000m3/h |
10 |
Standard discharge distance |
1500m |
11 |
Cut Width @ Maximum digging depth |
35m |
12 |
Cut Width @ Minimum digging depth |
44m |
2. Marine Diesel Engine to drive dredger pump
Item |
Main Diesel Engine |
Manufacturers |
JICHAI ENGINE |
Model |
8190ZLCZ-R |
Continuous Power |
720kw@1450rpm |
Amount |
1 Set |
Marine Diesel Engine to drive hydraulic system
Item |
Main Diesel Engine |
Manufacturers |
WEICHAI |
Model |
ZCW-6160 |
Continuous Power |
270kw@1000pm |
Amount |
1 Set |
3. Dredge Pump
Item |
Parameters |
Note |
Made |
Warman Technology, Australia |
SHIJIAZHUANG PUMP GROUP |
Type |
350G-H |
Professional Dredge Pump |
Capacity |
3000m3/h |
|
Head |
65 m |
|
Speed |
400—550 r/min |
|
Efficiency |
74—78% |
|
NpSHr |
small than 4.5 m |
|
Pump Suction Diameter |
400 mm |
|
Pump discharge Diameter |
350 mm |
|
Max.Diameter of Flowed Partice |
201 mm |
|
Solid Capacity |
450m³/h |
Count 15% solid |
