Bomba De Agua Periferica QB60
USD $12.8 - $16
/ Piece
1000 Pieces(Min.Order)
- 50000 Piece / Pieces per Month
- Fuzhou China.
- T/T
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | OEM or HUIHENG | |
| Model Number | QB60 | Theory | Vortex Pump | |
| Structure | Other, Peripheral Pump | Usage | Water | |
| Power | Electric | Standard or Nonstandard | Standard | |
| Fuel | Other, Electricity | Pressure | Low Pressure | |
| Application | Other, Clean water |
Product Description
Product Description
Pump casing: Cast Iron
Impeller: Brass
Motor Housing: Aluminum
Mechanical seal: Stainless steel(graphite to ceramic)
Shaft: 45# steel or stainless steel
Bearing: SKF/NTN/NSK/Chinese
Insulation class: B or F
Working conditions:
Protection class: IP44 and IP54
Max temperature of fluid up to: 50℃
Max ambient temperature up to: 40℃
Max Pressure: 10bar
INSTALLATION
INSTALLATION AND APPLICATIONS:
These pumps are suitable for handing clean water not containing abrasive particles and fluids which are not chemically aggressive to the pump components.
They are extremely reliable, light, economic and simple to use, finding many uses in domestic applications, in particular the automatic distribution of water from surge tanks, watering gardens and for boosting insufficient mains water pressure.
These pumps should be installed in a covered area, protected against the weather.
They are extremely reliable, light, economic and simple to use, finding many uses in domestic applications, in particular the automatic distribution of water from surge tanks, watering gardens and for boosting insufficient mains water pressure.
These pumps should be installed in a covered area, protected against the weather.
Perfermance.
PERPORMANCE:
The wide range of pumps in the QB series satisfies the most various operating requirements with features such as:
-high heads with respect to power requirements.
-Stable operating curves, with small variations in delivery rates with respect to large variations in the pressure demand.
-high tolerance of the presence of entrained air in the fluid to the pumped.
-Suction capacity up to 9 meters
-high heads with respect to power requirements.
-Stable operating curves, with small variations in delivery rates with respect to large variations in the pressure demand.
-high tolerance of the presence of entrained air in the fluid to the pumped.
-Suction capacity up to 9 meters
Model
| Power | Q.MAX (L/min) | H.MAX (m) | S.Head (m) | Speed (r.p.m) | Pipe Dia (Inch) | N.W (kg) | Packing size (mm) | |
W | HP | ||||||||
QB-60 | 370 | 0.50 | 35 | 35 |
9 |
2850 | 1″* 1″ | 5.3 | 265*120*152 |
QB-70 | 550 | 0.75 | 43 | 50 | 1″* 1″ | 8.5 | 310*138*172 | ||
QB-80 | 750 | 1 | 55 | 55 | 1.5″* 1.5″ | 10 | 315*138*180 | ||
