1HP - 2HP Bomba DTM Centrifugal Pump

1HP - 2HP Bomba DTM Centrifugal Pump photo-1
US$ 50 - 59 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
HUIHENG
Model Number:
DTM12, DTM16, DTM20
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou China
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Fujian, China
Brand Name HUIHENG
Model Number DTM12, DTM16, DTM20
Theory Centrifugal Pump
Structure Single-stage Pump
Usage Water
Power Other
Standard or Nonstandard Standard
Fuel Other
Pressure Low Pressure
Application Other, Pumping water

DTM Centrifugal Pump



Application

The centrifugal pump series are single stage pump. They are fitted with the overhand impeller directly splined by keyway on the motor shaft.



The liquid pumped is conveyed into the spiral shaped volute from the pump body, transforming the kinetic energy into dynamic pressure energy. Pressure and flow is achieved with minimum loss by the hydrodynamic closed impeller design.

Working conditions:

Protection class:   IP44 and IP54

Max temperature of fluid up to:  50℃

Max ambient temperature up to: 40℃



Structural characteristics:

Pump casing:  Cast iron

Impeller: Brass

Motor housing: Aluminum

Mechanical seal: Stainless steel(graphite to ceramic)

Shaft: 45# steel or stainless iron

Bearing: SKF/NTN/NSK/China

Insulation class: B and F

Protection class: IP44 and IP54

1HP - 2HP Bomba DTM Centrifugal Pump1HP - 2HP Bomba DTM Centrifugal Pump







For more information, please feel free to contact. We will supply you products with high quanlity and competitive price...



Terminal Board - Fire Retardant Material Terminal Board Could be Supplied.;

Thermal Protector - Could be added according to customer's requirement;

Logo: OEM service provided.  Could attach customer's nameplate( P.S. The authorization letter is needed);
