Standard configuration
Deutz 92KW
Joystick , one lever more convenient and saves manual power.
Heater inside cabin,specially for working in cold weather.
Manual floating function, when use the snow blade, more convenient.
17.5-25 standard tires. back sound, radio, USB, hand brake, warning light.
Mechanical transmission & Hydraulic torque converter
Performance | Rated loading | 3000kg |
Overall weight | 9600kg | |
Bucket capacity | 1.7-2.5m3 | |
Maximum dump height | 3100mm | |
Maximum dump reach | 1006mm | |
Overall dimension (L×W×H) | 7200*2470*3100 Mm | |
Minimum turning radius | 5097mm | |
Engine | Model | DEUTZ TD226B CUMMIN 6BT5.9-C130 |
Type | Vertical, in-line, water cooled, 4-stroke diesel engine | |
NO. of cylinder-bore*stroke | 6-108*125 | |
Rated power | 92/97kw—2200r/min | |
Transmission system | Torque converter | HangChi 428 |
Gearbox mode | Power shaft normally engaged straight gear | |
Gears | 2forward 1 reverse | |
Maximum speed | 40km/h | |
Hydraulic system | System working pressure | 16,5MPa |
Boom lifting time | 4.83 | |
Total time | 9.15±0.5s | |
Brake system | Service brake | Air assist disc brake on 4 wheels |
Parking brake | Manual disk brake | |
Tyre | Type specification | 17.5-25 |
Front tyre pressure | 0.4Mpa | |
Rear tyre pressure | 0.35Mpa |
HZM loader can do different job for you
Our products exported to all over the world
Shipping and packaging
1 set in a 40HQ(needs to remove cabin). Another small loader ZL08/ZL10/ZL12/ZL16could also be packed together.
Triangle wood and 10mm wire fixed.
We have 1 year warranty
if there is any part broken because of quality problem(except easy-damaged parts), sent the detailed pictures for us, then we will sent new parts for you.
We are specialized in mini wheel loaders as a professional manufacturer and exporter in China, all of our products are CE approved. We have many customers in European and American countries, now you can find our machines works in more than 32 countries.
If you are interested in our products please do not hesitate to contact me
