China 3ton zl936 wheel loader with CE

Specification

overall weight(kg)

9500

L×W×H(mm)

7050×2430X3120

rated bucket capacity(m³)

1.7

Rated load(kg)

3000

Maximum dump height (mm)

3020/3250

Bucket indicator

Yes

Max. breakout force(KN)

138

Engine

Model

                Deutz TD226B/Cummins 6BT5.9-C125

Type

                           In line,direct injection,

Rated power(kw)

92kw

Rated speed(r/min)

2200

Transmission    system

Model of torque converter

YJ320B

Type

single-phase single-stage radial-inward turbine triplex

Gearbox type

Fixed-spindle power shift

Gear shift

2 gears ahead,2 gear astern

  Hydraulic system

Distribution of work valve

DF25

Working pump

CBGj2100,CBGq2100

   Steering system

Type

Articulated hydraulic steering

Max. turning angle

                               lift and right 36.5±1°

Min turning radius(mm)

5862

    Brake system

Brake type

air-break brake

          Tyres

Standard tyres

17.5-25
