DSA-12 Direct Shear and Pre-press Apparatus (12 Cells)

Features:

a. The apparatus is a special presser to prepare the specimen for consolidation and fast shear test by adding vertical pressure on the soil specimen to make the specimen consolidation.

b. The apparatus includes consolidation cells, lever, weights and frame.

c. It is of weighing load and axial force.

d. Every consolidation cell can load 2 specimens.

e. This apparatus can do test on 24 specimens every time.

f. It is easy to operate.

Our products are 100% supplied from the factory

If you are interested in our products, you can contact us directly or welcome to visit our site:

SKYPE ID: sun.nancy3



Sample area	30cm²
Max. loading	1.2KN
Lever ratio	1:12
Max. loading	400Kpa
Loading grade	50, 100, 200, 300, 400Kpa
Consolidation cell	12 sets (can load 2 specimens)
