CTA-1A Automatic Pneumatic Consolidation Test Apparatus

Name: CTA-1A Automatic Pneumatic Consolidation Test Apparatus
Brand: GEOTEST EQUIPMENTS
SKU: 143207716
Availability: InStock

Shaoxing GeoTest Equipment Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

GEOTEST EQUIPMENTS

Model Number:

CTA-1A

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Shanghai Negotiable

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name GEOTEST EQUIPMENTS

Model Number CTA-1A

Power Electronic

Usage Other, Consolidation Test Apparatus

CTA-1A Automatic Pneumatic Consolidation Test Apparatus

Features:

a. Used to determine compressive performance of soil under the condition of different load and confining pressure.

b. It can make an experiments on standard consolidating and quick consolidation tests as well as testing consolidation compression and coefficient.

c. Complete with consolidometer, pneumatic controller, multi-channel converter and data acquisition system.

Our products are 100% supplied from the factory

If you are interested in our products, you can contact us directly or welcome to visit our site:

SKYPE ID: sun.nancy3

Load capacity	0-4.8KN
Loading precision	1. Absolute error is smaller than ±1.0Kpa when the load is smaller than 100Kpa 2. Relative error is smaller than ±1.0Kpa when the load is between 100Kpa and 1600Kpa
Sample area	30cm² or 50cm²
Air pressure control range	0-0.9Mpa
Pressure sensor	0-1.0Mpa
Channels of transducer	1-16 channels
Power supply	220V, 50Hz
Overall dimensions	390x188x230mm
Weight approx	50kg
