Temperature-controlled Pneumatic Consolidation Test Apparatus
This apparatus is used for doing the compression test on soil. It is used to determina the relations between distortion and the pressure or between the porosity ratio and the pressure and the relation between the distoryion and the time to calculate the unitsetting amount,the compression coefficient, the compression index, the rebound index, the consolidation coefficient of the compression moulds and so on.
Used to determine the consolidation parameters under the conditions of different moisture.
| Model | CTA-15/Temperature-controlled Pneumatic Consolidation Test Apparatus |
| Sample size | Φ61.8×20mm |
| Loading pressure | 1500Kma(pneumatic controlled) |
| Axial displacement | 10mm(dial gauge measure) |
| Input and output water measurment | 0-50ml |
| Temperature | room-temperature to 100℃ |
Temperature-cojntrolled Pheumatic Consolidation Test Apparatus
Temperature-cojntrolled Pheumatic Consolidation Test Apparatus Triple Soil Consolidation Device
The biggest manufactor is in china, the top quality is in china, the best service is also in china!
Pls believe GEOTEST, Believe China Power!
We sincerely lookinf forward to cooperate with you!
