ST-3M hand-static penetrometer/soil penetrometer / penetrometer test/ soil test kit
BS 1377, 1924, 812 EN 932-1
1. Characteristics
a. Static Penetrometer (penetrometer test, testing equipment, testing machine)
b. The device is lightweight, simple structure, easy operation, stable performance.
2. Specifications
Penetration capacity 3 tons, probe rod 28*5, 20 meters long.
3. The main technical parameter
Structure type |
light chain, both sides of hand, with supporting leveling mechanism |
|
Rated penetration force |
30KN (3 ton) |
|
Maximum penetration force |
33KN (3.3 ton) |
|
Penetration depth |
30m |
|
Penetration speed |
0.9 ~ 1.2 m / min (50-70 per minute hand turn) |
|
Lifting speed |
Slow speed can up to 4MPM (meter per minute) |
|
Penetration rod |
Every rod length 1m. Φ28 × 5-6 thick, high-quality alloy steel seamless pipe |
|
Anchor |
Diameter 220 ~ 260 mm, single leaf anchors, two |
|
Penetration head |
Strain single bridge head 10cm or double bridge head 10cm |
|
Chain |
Chain Drive |
10A-1 |
Drive chain |
12A-1 |
|
Weight of main machine |
≤ 60 kg |
|
4.Packing List
No. |
Name |
Specification |
Quantity |
Remark |
1 |
The Host |
|
1set |
|
2 |
The force transmission board |
|
1pcs |
|
3 |
Card board |
|
2pcs |
one for alternate |
4 |
Lengthening chain pin |
φ8 × 38 |
8pcs |
for alternate |
5 |
Ground anchor |
|
2pcs |
|
6 |
Anchor plate head |
|
1 |
|
7 |
Anchor rod afterburner |
|
2 |
|
8 |
Beams |
|
2 |
|
9 |
Penetration rod |
φ28 × 1m |
30 pcs |
|
10 |
Single bridge probe |
10 cm 2 |
1 |
|
11 |
Probe connector |
|
1 |
|
12 |
Four-core shielded cable |
40 meters |
1 |
|
13 |
Recording instruments |
DN-1 |
1 |
Users to purchase (USD200.00) |
14 |
Probe holder |
|
1 |
|
15 |
Certificate |
|
1 |
|
16 |
Instructions |
|
1 |
