VB-1 Vebe Consistometer /concrete Vebe Consistometer for Slump Test /Vebe Consistometer for Fresh Concrete Mixture
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanxi, China
Brand Name:
GEOTEST EQUIPMENTS
Model Number:
VB-1
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Water Column Type Concrete Air Content MeteNegotiableMOQ: 1 Set -
Penetration Drag Force Testing Equipment Standard Concrete PenetrometerNegotiableMOQ: 1 Set
-
Concrete Slump Flow TesterNegotiableMOQ: 1 Set
-
Concrete Waltz ContainerNegotiableMOQ: 10 Sets
-
CFA-1Concrete Compaction Coefficient TesterNegotiableMOQ: 1 Set
Place of Origin
Shanxi, China
Brand Name
GEOTEST EQUIPMENTS
Model Number
VB-1
Specifications
Vebe Consistometer1.use with slump test altogeter
2.With tamper rod and working table
VB-1 Vebe Consistometer
Characteristics:
a. This test method is a variation of the simple slump test and subjects the concrete to vibration after removal from the slump cone.
b. The time taken for the concrete to be recompacted is taken as a measure of workability.
c. The small vibrating table operates at a fixed amplitude and frequency, and in the test a plastic disc is placed into contact with the upper surface of the concrete.
d. The test is completed when the lower surface of the disc has been completely coated with cement grout.
|
Slump cone |
top dia. 100mm | |||||
| base dia. 200mm | ||||||
| height 300mm | ||||||
| Container | 240mm int. dia.x 200mm int. height | |||||
| Vibrator frequency | 3000r.p.m. | |||||
| Amplitude of vibration table | 0.5mm | |||||
| Motor power | 250W | |||||
| Timing range | 0.1-99.9s | |||||
| Overall dimension | 400x520x690mm | |||||
| Weight approx | 50kg | |||||
