Specifications
Multi-function CBR&Marshall Testing MachineGood and stable performance
Easy operation, long life
High efficiency
- Multi-function CBR&Marshall Testing Machine
Features
- The machine uses high-speed CPU design
- Large-screen LCD
- More accurate data
- The comprehensive saturated measures reduce the probability of instruments misuse damage
- You can do compression, Marshall stability
| Maximum rated load | 0-99.99KN, 0-30KN Resolution: 0.001mm Precision: better than 0.5% | |||||
| Displacement range | 0-15mm | |||||
| Maximum moving distance of screw rod | 200mm | |||||
| Motor speed | Fast speed: 50mm/min Slow speed: 1mm/min | |||||
| Manual speed | 0.2mm/crank each circle | |||||
| Motor specification | 750W | |||||
| Weight | 210kg | |||||
| Dimensions | 1200×700×1450mm | |||||
| Supply voltage | 380V | |||||
| Power | 1200W | |||||
| Environmental temperature | ≤35°C | |||||
| Relative humidity | ≤85% | |||||
