UNI-T Original Digital Clamp Multimeter UT58
US$ 22 - 48
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
UNI-T
Model Number:
UT58d
Payment & Shipping
Payment Methods:
Port of Shipment:
xingang
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Low Cost Multimeter Dt9208a Multimeter Uni-t MultimeterNegotiableMOQ: 1 Set -
Original Authentic UNI-T Dt9208a Digital MultimeterNegotiableMOQ: 1 Set
-
Best Digital Multimeter UNI-T UT71AUS$ 101 - 110MOQ: 1 Set
-
UNI-T UT71E Intelligent LCD Digital MultimeterUS$ 190 - 200MOQ: 1 Set
-
Portable Digital Clamp Multimeter UNI-T Hot SaleNegotiableMOQ: 1 Set
Place of Origin
Hebei, China
Brand Name
UNI-T
Model Number
UT58d
Measuring Current Range
10A
Measuring Voltage Range
1000V
Measuring Resistance Range
200 -200M
Measuring Capacitance Range
40mF
Measuring Inductance Range
1000V/1000V
Operating Temperature
0~40
Dimensions
179 x 88 x 39mm
Product Description
| Specifications | Range | Best Accuracy | |
| Model | UT58D | UT58E | |
| DC Voltage (V) | 200mV20V/200V/1000V | ±(0.5%+1) | |
| 200mV/2V/20V/200V/1000V | ±(0.05%+3) | ||
| AC Voltage (V) | 2V/200V/1000V | ±(0.8%+3 | |
| 2V/20V/200V/1000V | ±(0.5%+10) | ||
| DC Current (A) | 2mA/20mA/20A | ±(0.8%+1) | ±(0.5%+5) |
| AC Current (A) | 2mA/20mA/20A | ±(1%+3) | |
| 20mA/200mA/20A | ±(0.8%+10) | ||
| Resistance (Ω) | 200Ω/2KΩ/200KΩ/2MΩ/20MΩ | ±(0.8%+1) | |
| 200Ω/2KΩ/20KΩ/2MΩ/200MΩ | ±(0.5%+10) | ||
| Capacitance (F) | 20nF/200nF/2μF/100μF | ±(2.5%+5) | |
| 2nF/20nF/2μF/20μF | ±(3%+4) | ||
| Inductance (H) | 2mH/20mH/200mH/20H | ±(2%+10) | |
| Frequency (Hz) | 20KHz | ±(1.5%+5) | |
| Temperature (°C) | -40 °C ~ 1000°C | ±(1%+30) | |
| Features | |||
| Display Count | 2000 | 2000 | |
| Manual Range | √ | √ | |
| Diode | √ | √ | |
| Transistor | √ | √ | |
| Auto Power Off | √ | √ | |
| Continuity Buzzer | √ | √ | |
| Data Hold | √ | √ | |
| Low Battery Indication | √ | √ | |
| Full Icon Display | √ | √ | |
| Input Impedance for DCV | Around 10MΩ | √ | √ |
| Test Lead Connection Indications | √ | √ | |
| General Characteristic | |||
| Power | 9V Battery(6F22) | ||
| LCD Size | 60mm×54mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 350g (Including holster) | ||
| Product Size | 179mm×88mm×39mm | ||
| Standard Accessories | UT58D-Battery, Test Lead,Holster,Muli-Purpose Socket | ||
| UT58E-Battery, Test Lead,Holster,Muli-Purpose Socket,Point Contact Temperature Probe | |||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 40 PCs | ||
| Standard Carton Measurement | 598mm×418mm×340mm (0.085 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 27 Kg | ||
