Yugong Excavator Mini Excavator With US EATON Motor

Yugong Excavator Mini Excavator With US EATON Motor photo-1
Yugong Excavator Mini Excavator With US EATON Motor photo-2
Yugong Excavator Mini Excavator With US EATON Motor photo-3
Yugong Excavator Mini Excavator With US EATON Motor photo-4
Yugong Excavator Mini Excavator With US EATON Motor photo-5
Yugong Excavator Mini Excavator With US EATON Motor photo-6
US$ 100,000 - 150,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Model Number:
YG22-9X, YG22-9X
Condition:
New
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Model Number YG22-9X, YG22-9X
Condition New
Bucket capacity 0.1m3, 0.1m3
Maximum Digging Height 3720mm, 3720mm
Maximum Digging Depth 2630mm, 2630mm
Machine Weight 2200kg, 2200kg
Max Digging Radius 4900mm
Rated Speed 2.7Km/h
Certification ISO9001
After-sales Service Provided No overseas service provided

Chinese Hudralic Mini Crawler Excavator

Yugong excavator mini excavator with US EATON motora. The streamline modelling design, fashion and elegant appearance, reliable,highly cost effective.

b. small volume, working flexible, good at narrow spaces work.

c. Domestic mature and advanced hydraulic system,pilot control, 180 °, 360 ° rotation change-over valve can improve efficiency greatly.



A   Overall Length (trans pos)

4120mm

B   Overall Height (trans pos)

2250 mm

C   Width of Undercarriage

1320mm

D   Width of Track

250mm

F    Length Of Track

1621mm

H   Dist. Between Undercarriage And Ground

235mm

J   Width Of Platform

1130mm

L   Dist. Between Platform And Ground

490mm

E   Maximum Platform Tail Turning Radius

1290mm

I   Dist. Between Boom And Ground

1430mm

G   Sprocket To Idler Centres

1261mm



Operation Hydraulic Pressure

16Mpa(2320PSI)

Maximum Digging Force

≥12KN

Maximum Gradeadility

≥58%(30°)

Travelling Speed

≥2.7 km/h

Maximum traction

15 KN

Swing Speed of Platform

13rpm

Variable displacement pump capacity



Fixed displacement pump capacity

2X24.2+11L/min



A Maximum Digging Height

3720mm

B Maximum Dumping Height

2260mm

C Maximum Digging Depth

2630mm

D Maximum Digging Radius

4250mm

D1 Maximum Digging Dist.of Ground

4160mm

E Maximum Height Digging Radius

2750mm

F Maximum Platform Tail Turning Radius

1850mm

G Maximum Depth for Bulldozing

250mm

H Maximum Height for Bulldozing

230mm



Yugong excavator mini excavator with US EATON motor

Yugong excavator mini excavator with US EATON motor

Delivery time for order within available stock is in 7days

Delivery time for order without available stock is in 15days

Yugong excavator mini excavator with US EATON motor



After Service

1.Guarantee for a year.

2.Quality problem,we will send you the accessories.

3.Free repair whole using life(without the freight and accessories charge).

Yugong excavator mini excavator with US EATON motor

Qingdao Changqing Mining machine co., LTD. established in June 18, 1982, registered capital of 5.6 million . We have 4 branch companies in Jining ,Linyi and Qingdao

 Main products: Garden Machinery including tree spade , lawn mower, Skid Loader, Mini Excavator,Construction machinery and accessories, Road Marking and Mining equipment,Mining tools and so on. In July 2006 we passed the ISO9001:2000 certification.Our company products have been exported to the United States, Britain, France, Japan, Italy and more than 20 countries.

Yugong excavator mini excavator with US EATON motor

 Yugong excavator mini excavator with US EATON motor



What information do you want to know if i want to get a quotation?

 a). The model/size of your products.

 b). The application fo your products.

 c). Special package methods if you needs.

 d). Raw material.

Do you inspect the finished products?

Yes. Each step of products will be carried out inspection by QC department until shipping.

What advantages do you have?

(a).Punctual: Have your orders met with the latest delivery?

We are a manufacturer with so many advanced and new machines.

It ensures we have the ability to carry out the production schedual for punctual delivery.

(b).20-year production experience.  We have over 20 years exprerience in this industry.

That means we can preview the problems for the orders and production.

Therefore, it will make sure to deduce the risk of bad situation to happen.

(c). Point to point service.

There is two sales departments who will serve you from inquiry to products shipped out. During the

process, you just need to discuss with him for all the problems and the way sames much times.
