Borer/horizontal Boring Machine/boring Machine

Name: Borer/horizontal Boring Machine/boring Machine
Brand: SMAC
SKU: 143009890
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

CNC or Not:

Normal

Place of Origin:

Jiangsu, China

SJR Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not Normal

Place of Origin Jiangsu, China

Brand Name SMAC

Model Number 2M2216

Specifications

Cylinder Honing Machine/borer/horizontal boring machine/boring machine

*Borer/horizontal boring machine/boring machine*

Specification	Model	Unit	14301	14302	14303	14304	14305	14306
Specification	Model	Unit	2M2216	2M2217	MJ4214B	3M9816	3M9814	3MQ9814
Dia. of hole honed		mm	170	170	140	45-160	40-140	40-140
Max. depth of hole honed		mm	320	320	370	320	320	320
Spindle speed (rpm)		rpm	100-300	120-320	125-215	125, 250	128, 240	125, 250
Longitudinal travel honing head		mm	300	300-	350		700	340
Spindle lifting and lowering speed		m/min	3-18	0-18	3-10	0-12	0-10	0-10
Motor		kw	1.1	1.5	1.5	1.1	0.75	0.75
Overall size		cm	180 x 130 x 220	180 x 135 x 209	160 x 93 x 87	124 x 85x 231	146 x 96 x 161	129 x 88 x 201
Weight		kg	1.2	2	0.75	940	510	510

Cylinder Body And Surface Grinder

Aalve Grinding Machine

Model Specification	14309
Model Specification	3M9390A
Dia. of valve ground	30-90mm
Dia. of valve stems clamped	7-16mm
Angle of valve ground	30/60 degree
Machine head spindle speeds	120r/min
Grinding wheel spindle speeds	4270r/min
Motor power	0.37kW
Overall dimensions (L x W x H)	530 x 430 x 510mm
Weight	90kg
