Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TXM250A Cylinder Boring Machine for Engine RebulidNegotiableMOQ: 1 Set -
Boring Lathe MachineNegotiableMOQ: 1 Set
-
SMAC High Quality and Well Classic Boting MachineryNegotiableMOQ: 1 Set
-
Brake Drum Machine/Borer/boring Machine/three-row Drilling MachineNegotiableMOQ: 1 Set
-
Cylinder Boring & Surface Grinding-milling MachineNegotiableMOQ: 1 Set
Condition
New
CNC or Not
Normal
Place of Origin
Jiangsu, China
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Brand Name
SMAC
Specifications
Brake Drum Machine/Borer/boring machine/three-row drilling machine*Brake Drum Machine/Borer/boring machine/three-row drilling machine*
Specification | Model | Unit | 14801 | 14802 | 14803 | 14804 | 14805 |
T8346/1 | T8350 | T8358(A) | T8360 | T8365 | |||
Range of processing diameter | mm | 200-460 | 250-500 | 220-580 | 180-600 | 350-650 | |
Rotating speed of workpiece | rpm | 31, 59 | 41, 59 | 37, 50 | 27, 45, 70 | 30, 45 | |
Working travel of slideboard | mm | 140 | 200 | 320 | 450 | 450 | |
Motor (KW) | kw | 0.37 | 0.55 | 1.1 | 1.1 | 0.85/1.1 | |
Overall dimensions (L x W x H) | cm | 71 x 56 x 105 | 76 x 49 x 107 | 100 x 82 x 138 | 94 x 85 x 141 | 930 x 60 x 141 | |
Weight (kg) | kg | 87 | 145 | 650 x 750 | 800 | 900 | |
*Brake Drum/Disc Boring Machine*
Model | 14806 | 17807 | |
Specification | T845 | T846 | |
Max. diameter of bored hole | Φ500mm | Φ600mm | |
Max. diameter of bored disc | Φ400mm | Φ400mm | |
Max. depth of bored hole | 200mm | 200mm | |
Feeding | Stepless | Stepless | |
Max. cutting depth | 1mm | 1mm | |
Motor (YD802-4/6) depth | 0.75/0.55kw | 1.1/0.55kw | |
Over dimensions (L x H x W) | 1180 x 870 x 1370 | 1180 x 870 x 1370 | |
Gas Valve Seat Boring Machine
Model | 14808 | 14809 | 14808 | 14808 | |
Specification | TJ8563 | TJ8570 | TJ8590 | TJ8585 | |
Boring dia. of valve seats | 30-60mm | 35-70 | 20-990 | Φ25-Φ85 | |
Spindle travel | 10mm | 0.05feeding | 180 | 450 | |
Power | Manual | motor | |||
