Help CenterPeripheral Pump
Related Products
Specifications
Peripheral Pump1. Pump body: Cast Iron
2. Motor Support: Cast Iron
3. Impeller: Brass
Peripheral Pump Specification:
Operating conditions:
1. Liquid temperature up to 60ìC
2. Ambient temperature up to 40ìC
3. Total suction lift up to 8m
4. Continuous duty
Motor
1. Two-Pole induction motor(n=2900r. P. M. )
2. Insulation Class B/F
3. Protection IP44
Material
1. Pump body: Cast Iron/Brass insert
2. Motor Support: Cast Iron
3. Impeller: Brass
4. Shaft with rotor: Hi-Cr plated 45# Steel/Stainless Steel
5. Mechanical seal: Carbon/Ceramic
Application:
-Volumetric water pumps able to offer high pressures in relation to comparatively low powers and which have particularly steady operating curves.
-They are qualified in domestic fittings, to in crease the system pressure in aqueducts and for automatic water distribution by small autoclave tanks or by hydrosphere units.
-For the correct functioning of the pump, use clean water, or non-aggressive liquids only, without sand or other solid impurities.
NO. |
TYPE |
POWER |
MAX.FLOW |
MAX.HEAD |
INLET/OUTLET |
MAX.SUCT |
N.W |
PACKING DIMENSION |
|
(Kw) |
(Hp) |
(L/min) |
(m) |
(Inch) |
(m) |
(K.g) |
(mm) |
||
A |
QB60 |
0.37 |
0.5 |
35 |
35 |
1"*1" |
9 |
5.5 |
265*130*160 |
B |
QB70 |
0.55 |
0.75 |
45 |
50 |
1"*1" |
9 |
9.2 |
325*160*200 |
C |
QB80 |
0.75 |
1 |
50 |
60 |
1"*1" |
9 |
10.2 |
325*160*200 |
