4 INCH 1.5HP DEEP WELL SUBMERSILE BORE WATER PUMP 4SDM2/14

Specifications

Deep Well Submersible Bore Water Pump
1. Stainless Steel
2. Heavy Duty Cable
3. Starter Box

Deep Well Submersible Bore  Water Pump Specification:



Operating conditions:
-Liquid temperature up to 35^oC
-Submersion depth 40m
-Minimum internal diameter of well: 102mm.
-Continuous duty.

Motor:
-Tow-pole induction motor (n=2850r.p.m)
-Built-in over load motor protector
-Insulation Class B/F
-Protection IP68

Material:
-External pump body: Stainless Steel
-Suction strainer: Stainless Steel
-Impeller and diffusors: Noryl
-Bearing brackets: Brass
-Shaft: Stainless Steel
-Motor housing: Stainless Steel
-Mechanical seal: Ceramic/Graphite

Application:
-Multistage submersible water pumps with radial closed impeller conceived in order to solve any problem of clean water conveyance.
-Suitable for irrigation, and pressure systems and pressure systems and generally for civil and industrial purposes



FLOW RATES

• 17L/Min@91m
• 25L/Min@88m
• 33L/Min@85m
• 42L/Min@78m
• 50L/Min@70m

SPECIFICATIONS

• Motor: 1.5HP/1.1KW
• Phase: Single
• Voltage: 220-240V 50HZ
• Brass Outlet: 1.25" /1.5''
• Rev: 2850RPM
• Max Ambient Temp: 70C
• Max Fluid Temp: 40C
• Vertical/ Horizontal Mounting: Yes
• Max Starts Per Hour: 30
• Overload Trip Time: <10 Sec
• Insulation Class: B
• Plug: 10amp
• Max Head: 94m
• Protection Class: IP68
