Specifications
Deep Well Submersible Bore Water Pump1. Stainless Steel
2. Heavy Duty Cable
3. Starter Box
Deep Well Submersible Bore Water Pump Specification:
Operating conditions:
-Liquid temperature up to 35oC
-Submersion depth 40m
-Minimum internal diameter of well: 102mm.
-Continuous duty.
Motor:
-Tow-pole induction motor (n=2850r.p.m)
-Built-in over load motor protector
-Insulation Class B/F
-Protection IP68
Material:
-External pump body: Stainless Steel
-Suction strainer: Stainless Steel
-Impeller and diffusors: Noryl
-Bearing brackets: Brass
-Shaft: Stainless Steel
-Motor housing: Stainless Steel
-Mechanical seal: Ceramic/Graphite
Application:
-Multistage submersible water pumps with radial closed impeller conceived in order to solve any problem of clean water conveyance.
-Suitable for irrigation, and pressure systems and pressure systems and generally for civil and industrial purposes
FLOW RATES
- 17L/Min@195m
- 25L/Min@189m
- 33L/Min@180m
- 42L/Min@168m
- 50L/Min@150m
SPECIFICATIONS
- Motor: 3.0HP/2.2KW
- Phase: Single
- Voltage: 220-240V 50HZ
- Brass Outlet: 1.25" /1.5''
- Rev: 2850RPM
- Max Ambient Temp: 70C
- Max Fluid Temp: 40C
- Vertical/ Horizontal Mounting: Yes
- Max Starts Per Hour: 30
- Overload Trip Time: <10 Sec
- Insulation Class: B
- Plug: 15amp
- Max Head: 150m
- Protection Class: IP68
