DTM952R Total Station Price

Name: DTM952R Total Station Price
Brand: Max Germany
SKU: 142965940
Availability: InStock

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Max Germany

Model Number:

MDT-952R

Type:

Other, TOTAL STATION

A One Tools Trading L.l.c.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Brand Name Max Germany

Model Number MDT-952R

Type Other, TOTAL STATION

Material Other

Size 174X207X383mm

Specification:

Distance Measurement Section
Range	Non-prism	300m / 500m
	Prism	Single Prism: 3000m, Three Prism: 5000m
Accuracy	Non-prism	±(5mm+3ppm·D)
	Prism	±(2mm+2ppm·D),±(3mm+2ppm·D)
Unit		m/ft
Display		Max:99999999.99m,Min:0.1mm
Measuring time		Precise model:1S, Track model:0.8S
Number of time Set		1~99
Meteorologiccorrection		Input the value and correct automatic
Prism constant		Input the value and correct automatic
Angle Measurement Section
Method		Absolute coding
Grating diameter		79mm
Minimum reading		1''
Detection	Horizontal	Diametrical detection
	Vertical	Diametrical detection
Accuracy		2''
Telescope Section
Imaging		Positive
Length		170mm
Effective aperture		48mm
Magnification		30X
Angle of vision		1.5°
Distinguish ability		3.5''
Minimum focus distance		1.5m
Compensator
System		Double axis photoelectric tilt sensor
Working range		±3'
Distinguish ability		1''
Display Section
Type		Double sides,lattice 240X320 LCD,3.5 inch
		touching screen operation
Operation System		Microsoft Windows CE.NET 5.0
Data Transmission
Port		USB,RS-232C
RAM		1G(RAM)
Others
Plummet		Optical or Laser plummet
Power		DC7.4V, 4000mAh
Continuous working time		8 hours at least
Size		174X207X383mm
Weight		6.8kg
Working temperature		-20°C~50°C
