Help CenterReflect Coreless Total Station
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Max Germany
Model Number:
MDT-622R
Type:
Other, TOTAL STATION
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
Max Germany
Model Number
MDT-622R
Type
Other, TOTAL STATION
Material
Other
Size
174 X207X383mm
Laser beam focused in non-prism mode for 300m distance.
·Strong software to help to achieve the measurment.
·RS232 or USB ports for option.
·Good laserto protect the eyes of the surveyor.
·Large LED display.
MDT622R electronic total station SPECIFICATION :
| Model | MDT622R | |
| Distance Measurement Section | ||
| Range | Non-prism | 300m |
| Prism | Single prism:3000m,Three prism:5000m | |
| Accuracy | Non-prism | ±(5mm+3ppm.D) |
| Prism | ’±(2mm+2ppm.D),±(3mm+2ppm.D) | |
| Unit | m/foot | |
| Disply | Maximum | 99999999.999m |
| Minimum | 0.1mm | |
| Measuring time | Precise model:1s,Track model:0.8s | |
| Number of time Set | 1-99 | |
| Meteorologic correction | Input the value and correct automatic | |
| Prism constant | Input the value and correct automatic | |
| Angle Measurement Section | ||
| Method | Absolute coding | |
| Grating diameter | 79mm | |
| Minimum reading | 1" | |
| Detection | Horizontal | Diametrical detection |
| Vertical | Diametrical detection | |
| Accuracy | 2" | |
| Telescope Section | ||
| Imaging | Positive | |
| Length | 170mm | |
| Effective aperture | 48mm | |
| Magnification | 30x | |
| Angle of version | ‘1.5° | |
| Distinguish ability | 3.5" | |
| Minimum focus distance | 1.5m | |
| Compensor | ||
| System | Double axis photoelectric tilt sensor | |
| Working range | ’±3′ | |
| Distinguish ability | 1" | |
| Display Section | ||
| Type | Double sides,240*160 LCD Display | |
| Data Transmission | ||
| Port | USB,RS-232C | |
| Capacity | 40,000data at least | |
| Others | ||
| Plummet | Optical or Laser plummet | |
| Power | DC7.4V,4000mAh | |
| Continuous working time | 8 hours at least | |
| Size | 174*207*383mm | |
| Weight | 6.8KG | |
| Working temperature | ‘-20°C-50°C |
|
