Topographic Survey Instruments Total Station

Name: Topographic Survey Instruments Total Station
Brand: Max Germany
SKU: 142965944
Availability: InStock

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Max Germany

Model Number:

MDT-752R

Type:

Other, TOTAL STATION

A One Tools Trading L.l.c.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Brand Name Max Germany

Model Number MDT-752R

Type Other, TOTAL STATION

Material Other

Size 200mmx190mmx350mm

ECHNICAL DATA		MTD-752R
DISTANCE MEASUREMENT
Maximum	Reflector less	200m
	1P	4.0Km
Accuracy	Reflector less	5+3ppm
	Reflector	2+2ppm
Digital Display		Maximum: 9999999.999, Minimum: 1mm
Measuring Time		1st Fine Measurement: 2s, 2nd: 1.5s, Tracking: 0.5s
Atmospheric Correction		Input the parameter adjusted automatically
Prism Constant		Input the parameter adjusted automatically
ANGLE MEASUREMENT
Measurement Method		Absolute Encoding
Diameter of the Raster Disk (Horizontal/ Vertical)		79mm
Accuracy		2”
Detection Method		Horizontal: Dual, Vertical: Dual
TELESCOPE
Image		Erect
Length		154mm
Effective Aperture		45mm (DTM 50mm)
Magnification		30x
Field of View		1030’
Minimum focus		3”
Minimum Focusing Distance		1m
AUTOMATIC VERTICAL COMPENSATOR
System		Dual axis Liquid-Electric sensor Compensator
Working Range		± 3’
Accuracy		1”
SENSITIVITY OF VIAL
Plate of Vial		30"/2mm
Circular vial		8’/2mm
OPTICAL PLUMMET
Image		Erect
Magnification		30x
Focusing Range		0.5m-infinity
Field of View		50
DISPLAY
Type		Dual Side Graphic/Alphanumeric Dot Matrix LCD
MACHINE-CARRIED BATTERY
Power Supply		Rechargeable Ni-H Battery
Voltage		6V
Continual Operating Time		8 Hours
DIMENSION & WEIGHT
From Dimension		200mmx190mmx350mm
Weight		6.0 Kg
