Plastic Extrusion Blow Molding Machine

Name: Plastic Extrusion Blow Molding Machine
Brand: Lian Ji
SKU: 142754278
Availability: InStock

Ningbo Beyond Commodity Co., Ltd.

5Yrs

US$ 99 - 199 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Pipe

Plastic Processed:

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Pipe

Plastic Processed PP

Screw Design Single-screw

Automatic Grade Fully Automatic

Place of Origin Zhejiang, China

Brand Name Lian Ji

Model Number MP80D

Voltage 380V 50HZ

Power(W) 74.98 kw

Dimension(L*W*H) 4*2.3*2.5 m

Weight 8.2 T

Certification CE ISO9001

After-sales Service Provided Engineers available to service machinery overseas

Parameters

SPECIFICATIONS	material	PE PP PVC PA
	Max hollow product volume	10 L
	Diehead amount	1,2,3,4,6,8 Set
	Size(LXWXH)	4×2.3×2.5 m
	Machine Weight	8.2 Ton
CLAMPING	Clamping stroke	150 kN
	Template distance	220-620 mm
	Template stroke	400 mm
	Max template size(LXWXH)	520×460 mm
EXTRUDER UNIT	Screw Dia	80 mm
	Screw L/D ratio	24 L/D
	(HDPE)Plasticizing capacity(HDPE)	90 Kqh
	Screw heating zone	4 zone
	Screw heating power	19.6 kw
	Screw fan’s power	0.22 kw
	Extrusion motor’s power	30 kw
DIE HEAD	Diehead heating zone	2 zone
DIE HEAD	Diehead heating power	13.5 kw
ENERGY-CONSUMPTION	General power	74.98 kw
	Oil-pump motor power	11 kw
	Air pressure	0.6-0.8 Mpa
	Average power	35 kw
	Compressed air dosage	1.5 m³/min
	Cooling water dosage	40 L/min
