Plastic Blow Moulding Machines
US$ 99 - 199
MOQ: 1 Set
Key Specifications
Get Latest Price
Plastic Processed:
PP
Screw Design:
Single-screw
Automatic Grade:
Fully Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plastic Extrusion Blow Molding MachineUS$ 99 - 199MOQ: 1 Set -
Plastic Extrusion PanyUS$ 99 - 199MOQ: 1 Set
-
Plastic Extrusion Blow Molding MachineUS$ 1 - 199MOQ: 1 Set
-
LIANJI Plastic Extrusion Blow Molding MachineUS$ 99 - 199MOQ: 1 Set
-
Plastic Extrusion Blow Molding MachineUS$ 99 - 199MOQ: 1 Set
Plastic Processed
PP
Screw Design
Single-screw
Automatic Grade
Fully Automatic
Brand Name
LIAN JI
Model Number
MP45
Voltage
0.6-0.8
Power(W)
5500
Dimension(L*W*H)
2.6*1.75*2.3M
Weight
1.5T
Certification
CE ISO9001
After-sales Service Provided
Engineers available to service machinery overseas
Parameters
SPECIFICATIONS |
material |
PE PP PVC PA |
Max hollow product volume |
0.5L |
|
Diehead amount |
1,2,3 Set |
|
Size(LXWXH) |
2.6×1.75×2.35m |
|
Machine Weight |
1.5 Ton |
|
CLAMPING |
Clamping stroke |
30 kN |
Template distance |
80-200 mm |
|
Template stroke |
120 mm |
|
Max template size(LXWXH) |
170×200 mm |
|
|
EXTRUDER UNIT |
Screw Dia |
45 mm |
Screw L/D ratio |
24 L/D |
|
(HDPE)Plasticizing capacity(HDPE) |
25 Kqh |
|
Screw heating zone |
3 zone |
|
Screw heating power |
6.5 kw |
|
Screw fan’s power |
0.42 kw |
|
Extrusion motor’s power |
7.5 kw |
|
DIE HEAD |
Diehead heating zone |
2 zone |
Diehead heating power |
4 kw |
|
ENERGY-CONSUMPTION |
General power |
23.95 kw |
Oil-pump motor power |
5.5 kw |
|
Air pressure |
0.6-0.8 Mpa |
|
Average power |
12 kw |
|
Compressed air dosage |
0.6 m3/min |
|
Cooling water dosage |
30 L/min |
