Specifications
Construction Material Woven Geotextile1.Dimensional stability
2.Resistance to the biological and chemical environments
Woven Geotextiles
Woven Geotextiles Description
Geotextiles, the high strength polypropylene is widely used to filter, stabilize, reinforce, separate, drain and isolate soils in categories of civil construction applications. Polyester or Polypropylene woven fabrics and non woven fabrics are common and widely used form of geotextiles are commonly known as PP Non Woven geotextile or PP Woven geotextile. Geotextile swaps or condenses the requirement to utilize natural construction materials imparting economic and environmental benefits. We offer range of high strength woven geotextiles with GSM ranging from 80 to 250 and widths upto 5.20 mtrs to gratify various end user applications.
Woven Geotextiles Features
Geotextiles are valued in the market due to high tensile strength, low elongation and resistance to biological & chemical environments, resistance against all naturally occurring soil acids & alkalis and non- bacterial or anti-fungi properties. These are quality tested on various parameters to ensure their compliance with set international industrial standards. Further, we also customize our products to meet the specific requirements of the clients. Custom roll sizes, sewing and other geotextile fabrication services are available upon request.
Woven Geotextiles Special features:
|
Woven Geotextiles Technical Data Sheet
Item |
Testing Method |
Unit |
||
Grab Tensile Strength |
ASTM-D 4632 |
N |
890 |
1405 |
Grab Elongation |
ASTM-D 4632 |
% |
≤20 |
≤20 |
Puncture Strength |
ASTM-D 4833 |
N |
400 |
667 |
CBR Puncture |
ASTM-D 6241 |
N |
3200 |
4800 |
Mullen Burst |
ASTM-D 3786 |
kPA |
2578 |
4137 |
Trapezoidal Tear |
ASTM-D 4533 |
N |
500 |
750 |
Apparent Opening Size |
ASTM-D 4751 |
mm |
0.425 |
0.425 |
Permittivity |
ASTM-D 4491 |
Sec-1 |
0.05 |
0.05 |
Water Flow Rate |
ASTM-D 4491 |
1/m/m2 |
163 |
163 |
UV Resistance |
ASTM-D 4355 |
% 500hrs |
70 |
70 |
Roll Width |
m |
6 |
6 |
|
Roll Length |
m |
100 |
100 |
|
Mass |
GSM |
200 |
300 |
