pp geotextile, pp woven fabric, woven polypropylene geotextile
Description:
Made from PP (polypropylene) or PE (polyethylene) flit yarn on circle weave machine.
Specification:
1. 100g/m2-400 g/m2
2. 1m-4m in roll width
Property:
1. Light weight, high strength, low elongation, easy to construct.
2. Reinforcement, separation, drainage and filtration, fencing function etc.
Application:
It can be widely used in areas of railways, highways, sport fields, earthwork projects, tunnels, coal mines, walls and slopes, environmental protection, and so on.
3. Applications
Major functions: Separation, filtration, drainage, reinforcement, protection, and liquid barrier
1) Filtration
The filtration layer of the dykes, river canal, seacoast, concrete slope, retaining walls. At the same time of preventing the clay granule from passing, it allows the water and the gas pass through freely.
2) Separation:
The isolation of the railway dregs and the roadbed, roadbed and the soft base, surface of the airdrome and parking lot and the groundsill, different dam materials. It isolates the soil and the gravel of two kinds different granule pathway from the groundsill or other buildings.
3 )Adding muscle:
The highway, railway, soil-stone dam, breakwater, airport, backfill soil of retaining wall, slope protection, etc in which distributes the earth stress, prevents the side-displacement of the earth body and improves the earth body stability.
4 )Protection
It prevents the bank from being washed out, protects the bank and the bottom, prevents the water and soil from being washed away.
4. Technical Parameters
Quality per unit area(g/m2) |
120g |
160g |
200g |
240g |
280g |
340g |
400g |
After the breaking strength(KN/m)≥ |
20 |
30 |
40 |
50 |
60 |
80 |
100 |
Zonal breaking strength(KN/m)≥ |
15 |
22 |
28 |
35 |
42 |
56 |
70 |
Latitude and longitude to the elongation at break(%)≤ |
25 |
||||||
Trapezoidal tear strength (longitudinal)(KN)≥ |
0.2 |
0.27 |
0.34 |
0.41 |
0.48 |
0.6 |
0.72 |
Bursting Strength(KN)≥ |
1.6 |
2.4 |
3.2 |
4.0 |
4.8 |
6.0 |
7. |
Vertical permeability coefficient(cs/m) |
10-1~10-4 |
||||||
Equivalent aperture(O95mm) |
0.07-0.5 |
||||||
Deviation permit(%) |
±10 |
||||||
Remark |
Our company can make products based on the different requirement from customers. |
||||||
1. Specifications
1) Weight / Mass: 70g/m2-800g/m2 .
2) Width: Within 8 m (1m-8m).
3) Length: 50m-100m/roll (as request).
4) Material: PP/PET.
5) Color: Black , white , grey, others
6) Certificate: CE/ISO9001, ISO14001 .
7) Manufacturing method: nonwoven / woven.
8) The biggest geotextile manufacturer/factory in China for many years . The equipment is introduced from Germany.
9) This geotextile can be made of polypropylene (PP), or polyester (PET), Polyvinyl or synthetic fiber on needle punch machine.
10) The mass is available from 70g/m² to 800g/m² and the width available from 1.0m-8m, monolayer or multilayer (reinforcement geotextiles), long fiber or short fiber.
11) Color: all kinds of color are available. The annual production ability is 10 million square meters.
12) The fabric can also be heat treated by infrared at customer's requirements. Our geotextile are UV stabilized to give protection against aging under exposure to natural ultra-violet light.
