Specifications
200g PET geotextile factoryMaterial:PP/PET recycled or virgin
Width:1-6m
Weight:100-1200gsm
White/black
200g PET geotextile factory
200g PET geotextile factory Introduction:
200g geotextile factory are precisely manufactured with tested and examined high tenacity, low elongation synthetic fibers, i.e.PE and PP filaments. It is state leveled product with special processing and structures. It has extraordinary speciality against abrasion, punctuation and erosion. It can be conveniently used for protecting water ways: such as river, canal, strait, gorges, channel and drainage. It can also be used for water reservoirs, ponds, gulf, harbour, soft soil treatment, etc. It is a new technology in constructing civil engineering and water conservation.
200g PET geotextile factory Feature:
1.It can effectively make the concentrated stress diffuse, transfer or decompound, and prevent the soil mass against the destruction of outside force.
2.It can prevent the mixture of sandstone, soil mass and concrete of upper and lower layers.
3.Its mesh is hard to jam by virtue of the compliancy and motility of the reticulation formed by indefinite form fibrous tissue.
4.High water permeability-it can keep good water permeability even in the pressure of soil and water.
5.Corrosion resistant-it is made from polypropylene fiber or terylene or other chemical fiber, featuring resistance to acid and alkali and oxidation, non-corroding, no worm-eaten.
6.Easy construction-low weight, easy operation, simple construction
200g PET geotextile factory Application:
1.Filtration :
It can be the filtration layer of the dykes, river canal, seacoast, concrete slope, retaining walls. At the same time of preventing the clay granule from passing, it allows the water and the gas pass through freely.
2.Separation :
The isolation of the railway dregs and the roadbed, roadbed and the soft base, surface of the airdrome and parking lot and the groundsill, different dam materials. It isolates the soil and the gravel of two kinds different granule pathway from the groundsill or other buildings.
3.Reinforcement/Roofing :
The highway, railway, soil-stone dam, breakwater, airport and backfill soil of retaining wall, slope protection, etc in which distributes the earth stress, prevents the side-displacement of the earth body and improves the earth-body stability. Also, used as a waterproofing substrate for roofing industries
4.Protection :
It prevents the bank from being washed out, protects the bank and the bottom, prevents the water and soil from being washed away
200g PET geotextile factory Index:
Item |
Specification |
||||||||
100 |
150 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
|
|
Nominal Breaking strength,KN/M
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Breaking strength,MD/CD,KN/M≥
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Elongation at break,%
|
40-80 |
||||||||
|
CBR Mullen Burst Strength,KN≥
|
0.8 |
1.6 |
1.9 |
2.9 |
3.9 |
5.3 |
6.4 |
7.9 |
8.5 |
|
Tear strength,KN≥
|
0.14 |
0.21 |
0.28 |
0.42 |
0.56 |
0.70 |
0.82 |
1.10 |
1.25 |
|
Sieve size O90(O95),mm
|
0.05-0.20 |
||||||||
Vertical Permeability Coefficient, cm/s |
K×(10-1-10-3), K=1.0-9.9 |
||||||||
Thickness,mm≥ |
0.8 |
1.2 |
1.6 |
2.2 |
2.8 |
3.4 |
4.2 |
5.5 |
6.8 |
Width Variation,% |
-0.5 |
||||||||
Weight Variation,% |
-5 |
||||||||
Remarks |
We also can produce almost double Strength higher than the chart show |
||||||||
