Specifications
200g geotextile manufacturer in chinaMaterial:PP recycled or virgin
Width:1-6m
Weight:100-1200gsm
White/black
200g geotextile manufacturer in china
200g geotextile manufacturer in china Introduction:
Material |
PP(polypropylene) ,PET(polyester) |
Technics/process |
Needle punched / thermally bonded |
Specification |
100g/m2—1200g/m2 |
Width |
1m—6m(as you demand) |
Length |
50-100m(as you demand) |
Colour |
White, black,grey or as your request |
Packing |
PE film and woven cloth width 1-6m length50-100m |
Load |
According to your specification |
Payment terms |
T/T, L/C, western union,paypal |
Delivery time |
Within 5-7 days after your payment |
Application |
Geotextiles with various indicators of quality, with good stress -strain and toughness, seepage performance and uniformiy etc., And is applicable to roads, water, rail, mining dams, rivers, airports and other civil engineering, anyone in the works played reinforcement, segregation, filtration, filtration, drainage, and then extend the project life, reduced cost and easy construction, and it is easy to ensure the quality of the project. |
200g geotextile manufacturer in china Feature:
1.Good water permeability
2.Corrosion resistance
3.Microbial resistant
4.Good permeability
5.Good water conductivity
6.High tensile strength
7.Strong resistance to deformation
8.The mesh is not easily blocked
200g geotextile manufacturer in china Application:
1.Filtration :
It can be the filtration layer of the dykes, river canal, seacoast, concrete slope, retaining walls. At the same time of preventing the clay granule from passing, it allows the water and the gas pass through freely.
2.Separation :
The isolation of the railway dregs and the roadbed, roadbed and the soft base, surface of the airdrome and parking lot and the groundsill, different dam materials. It isolates the soil and the gravel of two kinds different granule pathway from the groundsill or other buildings.
3.Reinforcement/Roofing :
The highway, railway, soil-stone dam, breakwater, airport and backfill soil of retaining wall, slope protection, etc in which distributes the earth stress, prevents the side-displacement of the earth body and improves the earth-body stability. Also, used as a waterproofing substrate for roofing industries
4.Protection :
It prevents the bank from being washed out, protects the bank and the bottom, prevents the water and soil from being washed away
200g geotextile manufacturer in china Index:
Item |
Specification |
||||||||
100 |
150 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
|
|
Nominal Breaking strength,KN/M
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Breaking strength,MD/CD,KN/M≥
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Elongation at break,%
|
40-80 |
||||||||
|
CBR Mullen Burst Strength,KN≥
|
0.8 |
1.6 |
1.9 |
2.9 |
3.9 |
5.3 |
6.4 |
7.9 |
8.5 |
|
Tear strength,KN≥
|
0.14 |
0.21 |
0.28 |
0.42 |
0.56 |
0.70 |
0.82 |
1.10 |
1.25 |
|
Sieve size O90(O95),mm
|
0.05-0.20 |
||||||||
Vertical Permeability Coefficient, cm/s |
K×(10-1-10-3), K=1.0-9.9 |
||||||||
Thickness,mm≥ |
0.8 |
1.2 |
1.6 |
2.2 |
2.8 |
3.4 |
4.2 |
5.5 |
6.8 |
Width Variation,% |
-0.5 |
||||||||
Weight Variation,% |
-5 |
||||||||
Remarks |
We also can produce almost double Strength higher than the chart show |
||||||||
