plastic soil stabilization fiberglass geogrid1.Tensile strength in warp & weft direction;
2.Mesh size:12.7,25.4,50mm.
plastic soil stabilization fiberglass geogrid
plastic soil stabilization fiberglass geogrid Description
plastic soil stabilization fiberglass geogrid made of excellent reinforcement non-alkali fiberglass yarn and coated with excellent modified asphalt coating treament is a kind of plane network shape material. It is weaven into base material by using advanced warp knitter and adopts warknitted directional structure. Warp-knitting structure makes full use of yarn strength in textile and greatly improves geogrid's chemical performance makeing it have good tension resistance,tearing resistance and creep resistance.
plastic soil stabilization fiberglass geogrid features
(1)High tensile strength in both the warp and weft directions;
(2)Low elongation;
(3)Excellent temperature range;
(4)Good anti-age and alkali-resistance;
(5)Reduce construction cost, extend service life of road and prevent deflection cracks
plastic soil stabilization fiberglass geogrid Range
1.To reinforce old asphalt concrete road surface and asphalt surface layer, and prevent damage;
2.To rebuilding cement concrete road surface into composite and restraining reflection caused by block contraction;
3.Used in road expansion and improvement project and creak caused by old and new combination position and uneven sedimentation.
4.It is used in soft soil base reinforcement treatment, sutible for soft soil water separation and concretion,restrains sedimentation effectively,distributes stress uniformly and improve overall strength of road base.
plastic soil stabilization fiberglass geogrid Technical Parameters
Specification | EVA1×1 | EVA1×1 | EVA1×1 | EVA1×1 | EVA1×1 | EVA2×2 | EVA2×2 | |
Strength | Long . Horiz | ≥30 | ≥50 | ≥60 | ≥80 | ≥100 | ≥60 | ≥80 |
≥30 | ≥50 | ≥60 | ≥80 | ≥100 | ≥60 | ≥80 | ||
Percentage of Elongation | 4% | 4% | 4% | 4% | 4% | 4% | 4% | |
Size of Hole mm | 25.4×25.4 | 25.4×25.4 | 25.4×25.4 | 25.4×25.4 | 25.4×25.4 | 12.7×12.7 | 12.7×12.7 | |
Flexibility | 76 | 76 | 76 | 76 | 76 | 76 | 76 | |
Width M | 1--6 | 1--6 | 1--6 | 1--6 | 1--6 | 1--6 | 1--6 | |
Temperature | -100200 | -100200 | -100200 | -100200 | -100200 | -100200 | -100200 | |
