Perforated HDPE Geocell

Specifications

Perforated HDPE Geocell
Distance of welding:330-550mm
Stretched size:4x5-6x7m
Quick and easy to install
Strong and light



                     Perforated HDPE Geocell



Perforated HDPE Geocell Feature:



1. In load support applications, a high degree of frictional interaction is developed between the aggregate infill and the cell wall that directly increases the stiffness of the system by reducing the ability of a shear plane developing between the infill and the cell wall.
2. In all application areas, the perforations allow water to move from cell to cell reducing undesirable cell ponding and providing lateral drainage.
3. In vegetated slope and channel protection systems, roots can grow through the perforations increasing the stability of the vegetated cover when subjected to gravitational and hydrodynamic forces.

 Perforated HDPE Geocell Applications:

1.Be used for firm the roadbed of railroad;
2.Be used for firm highway soft foundation handling;
3.Be used for dike and retaining wall, which can bear load force;
4.Be used to harness the shoal water runway;
5.As pipeline and the sewer's propping up structure;
6.Be used for mixed type retaining wall that prevent the slope from falling down and bear load force;
7.Be used for independent wall, dock and breakwater;
8.Be used to harness the desert, beach and riverbed ,river bank.



 Perforated Geocell for Slope Erosion Control and Stabilisation Construction Methord:



1.Unfolding the geogrid (Some fiber-material can be put under the geogrid according to the concrete condition,for example geotextile and felted cushion.)
2.Fixing it with nail or connecting with the frame of stretcher;
3.Used loader to fill with filler until it is full top and beyond of the geogrid, then through vibration
and rolling, the subbase is completed.
4.By now, the system of geogrid can prop up kinds of construction equipment, and that construction directly above it is accepted, together with conventional manner surface .



Perforated Geocell for Slope Erosion Control and Stabilisation Infill opinion:

A variety of infill materials can be used with the geocell system based upon the requirements of the specific project/problem.

• Topsoil with various selected vegetation.
• Aggregates from sand and gravel to larger rock or stone.
• Concrete of various strengths and surface finishes.
• Combinations of the above to meet special conditions.

Perforated Geocell for Slope Erosion Control and Stabilisation  Index:



Item Model	Height (mm)	Welding distance (mm)	Sheet thickness (mm)		Tensile yield strength of the cell (MPa)	Seam peel strength (N/10cm)
			smooth	textured
TGLG-50-400	50	400	1~1.1	1.4~1.5	20.0	1000
TGLG-100-400	100	400	1~1.1	1.4~1.5	20.0	1000
TGLG-150-400	150	400	1~1.1	1.4~1.5	20.0	1000
TGLG-200-400	200	400	1~1.1	1.4~1.5	20.0	1000
TGLG-75-330	75	330	1~1.1	1.4~1.5	20.0	1000
TGLG-100-330	100	300	1~1.1	1.4~1.5	20.0	1000
TGLG-150-330	150	330	1~1.1	1.4~1.5	20.0	1000
