Road Construction Filament Spunbond Needle Punched Geotextile
- 400 Square Meter / Square Meters per Month
- Qingdao
- T/T
You May Like
-
PET Filament Spunbond Needle Punched Geotextile Fabric Price
-
Filament Spunbond Non-woven Geotextiles Fabrics for Sewage Treatment
-
Filament Spunbond Nonwoven Geotextile High Strength
-
Filament Spunbond Nonwoven Geotextile Fabric for Retaining Wall
-
Puncture Resistance Filament Spunbond Needle Punched Nonwoven Geotextile
-
Continuous Filament Needle Punched Geotextile
Product Details
| Place of Origin | Shandong, China | Brand Name | STARRING | |
| Model Number | FNG | Geotextile Type | Non-Woven Geotextiles |
Product Description
Specifications
Road Construction Filament Spunbond Needle Punched Geotextile1.Excellent drainage performance
2.Separation reinforcement
Road Construction Filament Spunbond Needle Punched Geotextile
Product Description
100% Polyester Filament Spunbond Needle Punched Geotextile is made by polyester filament,
featured with good physical property,high tensile, resisiting tearing,bursting,stabling,etc.It
boasts excellent drainage,separation,filtration and protection performance.
Product Features
There are four primary uses of geotextiles in roadway construction and maintenance:
1.separation or stabilization
2.drainage
3.erosion control
4.reinforcement
Product Specifications and Technical Parameters
item
| Value
| ||||||||||
Nominal breaking strength /(KM/m) | 4.5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | ||
1 | Breaking strength(MD/CD)(KN/m) | 4.5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | |
2 | Elongation at break (MD/CD)/% |
40-80 | |||||||||
3 | CBR mullen burst strength KN≥ | 0.8 | 1.6 | 1.9 | 2.9 | 3.9 | 5.3 | 6.4 | 7.9 | 8.5 | |
4 | Tear strength/KN | 0.14 | 0.21 | 0.28 | 0.42 | 0.56 | 0.70 | 0.82 | 1.10 | 1.25 | |
5 | Sieve size O90 mm | 0.05-0.20 | |||||||||
6 | Vertical permeability coefficient cm/s | K×(10-1-10-3)K=1.0-9.9 | |||||||||
7 | Thickess/mm ≥ | 0. 8 | 1.2 | 1.6 | 2.2 | 2.8 | 3.4 | 4.2 | 5.5 | 6.8 | |
8 | Width variation% | -0.5 | |||||||||
9 | Weight variation | -5 | |||||||||
Application Range
Used in the area of highway, railway, dam, coastal beach for rein forcement, filtration, separation and drainage, especially used in salt marshes and garbage burying field. Mainly in filtration, reinforcemnent and separation.
Geotextile joints to connect
General Geotextile joints to connect there is overlap, welding and oversew three ways.
Note:If geotextile joints to connect on the flat ground, overlap width>30cm.
If geotextile joints to connect not on the flat ground, overlap width>50cm.
Used for the mine project
