Specifications
Polyester Yarns Spunbond Non Woven Geotextile1.Excellent drainage performance
2.Safe and easy for construction
Polyester Yarns Spunbond Non Woven Geotextile
polyester yarns geotextiles Product Description
Filament spunbond needle punched geotextile is made by Dacron PET,
polyester yarns geotextiles Product Features
The products featured with good physical property:
- high tensile
- resisiting tearing
- bursting
- stabling
- It boasts excellent drainage,separation,filtration and protection performance.
polyester yarns geotextiles Application Range
Widely used in highway, railway,dam,coastal shoal engineering reinforcement,inverted filter,islation and drainage.
polyester yarns geotextiles Product Specifications and Technical Parameters
|
NO.
|
Item Specification Value |
Specification
|
||||||||||
100 |
150 |
200 |
250 |
300 |
350 |
400 |
450 |
500 |
600 |
800 |
||
1 |
Weight Variation % |
6 |
6 |
6 |
5 |
5 |
5 |
5 |
5 |
4 |
4 |
4 |
2 |
Thickness mm |
0.8 |
1.2 |
1.6 |
1.9 |
2.2 |
2.5 |
2.8 |
3.1 |
3.4 |
4.2 |
5.5 |
3 |
Width Variation % |
0.5 |
||||||||||
4 |
Breaking Strength KN/m |
4.5 |
7.5 |
10.5 |
12.5 |
15.0 |
17.5 |
20.5 |
22.5 |
25.0 |
30.0 |
40.0 |
5 |
Elongation Break % |
4080 |
||||||||||
6 |
CBR CBR Mullen Burst Strength KN |
0.8 |
1.4 |
1.8 |
2.2 |
2.6 |
3.0 |
3.5 |
4.0 |
4.7 |
5.5 |
7.0 |
7 |
O9095 Sieve Size O90 mm |
0.070.2 |
||||||||||
8 |
Vertical Permeability Coefficient cm/s |
(1.0-9.9)×(10-110-3) |
||||||||||
9 |
Tear Strength KN |
0.14 |
0.21 |
0.28 |
0.35 |
0.42 |
0.49 |
0.56 |
0.63 |
0.7. |
0.82 |
|
polyester yarns geotextiles picture information
