Introduction:
Video curtain can create fantanstic patterns in the stage . It uses super bright RGB leds. It has more working mode;Seperate working patterns and sound activate mode. Customer can control by DMX or DVI ,or SD card . It can adjust the working speed.
With the SD card controller, it can operate with auto run mode, sound activation mode . Users can also control the animation cloth with DMX desks . At DMX 512 mode ,users can select patterns in SD card,running speeds are also adjustable with DMX desk . Present patterns can be control up to 6 pcs 6x4m curtains. In case users need more than 6 curtains , controllers can be coonnected one to another in series .all curtains can be configurated ( with free software ) to work as one larger curtains and show just one pattern on the whole curtain . Pattern can be activated via all operation modes. This curtain can also show texts or logoes ( wih bigger size or higher resolution ).
Funciton:
- It with Emitting and stroboflash effects which can be used for decorating stage backdrop .
- It is widely used as stage backdrop and indoor decorative background.
- It is preinstalled with several auto-run animations program which makes the frames more showy and dazzling.
| Model No | S-SPB-P40 | S-SPB-P85 | S-SPB-P100 | S-SPB-P185 | S-SPB-P200 | ||
| Pixel pitch | P40mm | P85mm | P100mm | P185mm | P200mm | ||
| Pixel density per Unit( pc) | 3750 | 864 | 600 | 210/176 | 600/450 | ||
| Pixel density per square meter | 625 pcs LED/square meter | 140 pcs LED/ square meter | 100pcs LED / square meter | 36 pcs LED / square meter | 25pcs LED / square meter | ||
| Power consumption per square meter | 250W/ square meter | 55W/ square meter | 40W / square meter | 15W / square meter | 10W / square meter | ||
| Pixel configuration | F5 super brightness led | ||||||
| Brightness adjustment | 256 level | ||||||
| viewing angle | 120 degree | ||||||
| out of control point | <0.0002 | ||||||
| Lifespan | >50000 hours | ||||||
| working temperature | Miner 10 to 40 degree | ||||||
| Humidity | 10% to 90% | ||||||
| Protection level | IP44 | ||||||
| working Voltage | AC85~256V | ||||||
| control system | DMX 512,3-pin XLR input /output connector ,4 pin data output | ||||||
| DVI | |||||||
| Auto-run | |||||||
| Sound activation | |||||||
| cloth material | Flame retardant, heavy duty cloth ,fireproof material | ||||||
