High qualit F series Rubber Piston for Mud Pump
Piston assembly is the major part of the mud pump fluid end. The discharge pressure of mud pump is generated by the up-and-down motion of the piston in the cylinder. Small piston—high pressure and low flow rate; Big piston—low pressure and high flow rate. Metric pump and inch pump adopts metric piston and inch piston respectively. Generally, φ170, φ160, φ150 and 6″, 6-1/2″, 7″, etc.,used most.
Features:
1. Model: F series
2. Size: 4"- 7"
3. Medium temperature: Normal Temperature
4. Materials: HNBR / PU / NBR / PU composite
5. Pressure: High Pressure
6. Structure: piston pump
| Description | Temperature Range | Pump Pressure | Abrasion | Drilling Fluid | Application For |
| NBR | -40~100 °C |
5000PSI(35Mpa) |
Not Bad |
Water base |
Seals, Piston Rubber, Valve Rubber, Bladder |
-40~210 °F | |||||
polyurethane |
-40~85 °C |
5000PSI(35Mpa) |
Excellent |
Water base & Oil base |
Seals, Piston Rubber, Valve Rubber, |
-40~185 °F | |||||
HNBR |
-50~150 °C |
7500PSI(52Mpa) |
Good |
Water base & Oil base |
Piston Rubber, Valve Rubber, Bladder |
-58~300 °F | |||||
Viton |
-15~250 °C |
7500PSI(52Mpa) |
Not Bad |
Oil base |
Seals |
if any inquires , please fell free to contact us.
