Help CenterMEGATRO 220KV Transmission Line SZ2 Double Circuit Drum Type Suspension Tower
Related Products
-
MEGATRO 220KV Transmission Line ZB1 Horizontal Type Suspension TowerUS$ 920 - 960MOQ: 1 Ton -
MEGATRO 220KV 2E10 SJC4 Tension Angle Transmission TowerUS$ 920 - 960MOQ: 1 Ton
-
MEGATRO 220KV 2D1 SJ4 Heavy Angle Tension Transmission TowerUS$ 920 - 960MOQ: 1 Ton
-
MEGATRO 220KV 2E10 SJC3 Suspension Transmission TowerwerUS$ 920 - 960MOQ: 1 Ton
-
MEGATRO 220KV 2E10 SJ4 Tension Angle Transmission TowerUS$ 920 - 960MOQ: 1 Ton
This photo refers to 220KV transmission line SZ2 double circuit drum type suspension tower, double earth wire. There have horizontal cross-arm on top of earth wire support structure. Some of their technical data as follow:
No. |
2-40+1 |
Application scope |
220kvtranssmission line |
Pole （including tower type） |
SZ2 suspension tower（cavel double drum shape tower） |
||
Design condition | |||
Conductor type |
2×LGJ-240 |
Nominal height(m) |
steel weight（kg） |
Earth wire type |
GJ-50 |
33 |
14319.8 |
d speed（m/s） |
30 |
36 |
15441.5 |
Max.ice（mm） |
10 |
||
Horizontal span（m） |
650 |
||
Vertical span(m) |
900 |
||
Angle |
|||
Remark: above technical data only references for our client, we can design every type for our overseas clients.
MEGATRO is a full service engineering company with a global reputation for delivering excellence and innovation in power transmission, transformation, distribution, and telecommunications systems. Our MEGATRO provide and design this type 220KV transmission line SZ2 double circuit drum type suspension tower mainly for our overseas client. Since 2004, MEGATRO focus mainly international market and had export many kind of transmission structures to overseas clients. MEGATRO has been manufacturing lattice transmission tower & tapered steel poles for lighting, traffic control, communication and utility applications. MEGATRO pioneered the development of transmission tower, telecom tower, substation, and other steel structure and was also at the forefront in the design of Transmission tower.
Over 10 years of experience and innovation in engineering, designing and building towers has evolved MEGATRO into its current form:
l Full Turn-Key provider including site acquisition, engineering services, manufacturing, field services-DAS, tech services, value added reseller and monitoring, maintenance and network ownership
l Specialize in developing supplying and building wireless and wired networks and in-building telecommunications systems, as well as energy infrastructure
l Single source from Design to System Integration
l Top quality, ISO 9001 registered
A complete selection of towers including self-support, lattice steel tower, monopoles and guyed towers, form custom-designed radar towers to broadcast towers and energy infrastructure. MEGATRO carries a variety of related products including fall protection, transmission lines, antennas, obstruction lights, and accessories, and other products if client need, MEGATRO also tailored product as per client condition.
MEGATRO mainly design all kinds of towers and posts for:
a. Telecoms
b. Power transmission
c. TV and Radio Broadcast
d. Roads and City Development
e. Wind energy solution
f. Steel structure and workshop
