MEGATRO 220KV 2E10 SJC3 Suspension Transmission Towerwer

Name: MEGATRO 220KV 2E10 SJC3 Suspension Transmission Towerwer
Brand: Megatro
Availability: InStock

FOB Price

US$ 920 - 960 / Ton

1 Ton(Min. Order)

Port Qingdao or as per clients
Payment TermsT/T L/C
Delivery Detail30 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Megatro		Place of Origin	China
Model Number	MGP-220kv-2E10-SJC3

Product Description

MEGATRO 220KV 2E10 SJC3 suspension Transmission tower

This photo refers to our 220KV 2E10 SJC3 suspension Transmission tower, it is widely used in our Chinese market. Some of technical features of this tower as follow:

1 climate condition

Item	Temperature (℃)	Wind speed (m/s)	Ice thickness (mm)
Max. temperature	40	0	0
Mini. temperature	-20	0	0
Ice thickness	-5	10	15
Basic wind speed	15	25	0
Installation condition	-10	10	0
Annual temperature	15	0	0
Lightning overvoltage	15	10	0
Operation overvoltage	15	15	0
Hot-line work	15	10	0

2 tower design data

Tower

type

Nominal

Height

(mm)

Horizontal

span

(m)

Vertical

Span

(m)

Angle

Insulator

Type

Horizontal

Span at angel condition

2E10 SJC3

500

750

40 -60

Conductor type: 2×LGL-400/50

OPGW: JLB-150

3 Tower estimated weight and foundation force

Tower

Type

Tower weight scope (kg)

Foundation force scope (KN)

T_max

T_x

T_y

N_max

N_x

N_Y

2E10 SJC3

22524～32262

1553～1765

249-274

238～264

1853～2088

295～327

274～317

4Here is the design strength of Chinese tower steel

Steel material		Anti-push, bending and press strength (N/mm²)	Anti-shear strength (N/mm²)
Grade	Thickness or diameter (mm)	Anti-push, bending and press strength (N/mm²)	Anti-shear strength (N/mm²)
Q235 Steel	≤16	215	125
	>16～40	205	120
	>40～60	200	115
	>60～100	190	110
Q345 Steel	≤16	310	180
	>16～35	295	170
	>35～50	265	155
	>50～100	250	145
Q420 Steel	≤16	380	220
	>16～35	360	210
	>35～50	340	195
	>50～100	325	185
Q460 Steel	≤16	415	240
	>16～35	395	230
	>35～50	380	220
	>50～100	360	210
