Metal steel slitting machine, slitting line, metal sheet cutting machine
Feixiang Slitting machine is a kind of machine of getting narrow coils from main coils. For widths of up to1600mm, thicknesses of up to 5 mm and speeds of up to 60m/min. The lines are composed of high-precision slitters with quick tooling change for slitter, tensioning device and recoiler. High-capacity recoilers . Extraction from coils without banding. Scrap ballers or scrap choppers. Moving tensioning devices with incorporated levelling. Totally computer-controlled with diagnosis, automatic coil feed and quality control. For carbon steel, exposed and non exposed materials , stainless steel,pre-painted steel, aluminium and other metals.
Metal steel slitting machine: The three critical determinants of slitting cutter slitts line include on Slitting machine : •The work piece material thickness •Which type of material to be slit, for example, if stainless steel, we have to use special material cutting blade. •The tolerances that must be held while slitting. Now we also have one quite simply slitting machine, you need to make it work manuully. This set of slitting machine is suit for low amount of work. And the price for this machine is quite cheap. Main specification of steel slitting line . 1.Raw Material 1). Material : carbon steel and others 2). The thickness of the material:0.4mm-5mm. 3).Width:10mm,12mm,15mm,20mm,25mm,30mm. 40mm,50mm,60mm 4),Input width:600-1600mm 2. the process Decoiler ----flatting and cutting---slitting-----flatting and collecting 3.Hydraulic Decoiler with car 1). The inner size:450--610mm 4. Flatting and Cutting System 1). 2 shafts for feeding coil.9 shafts for flatting 2).material of flatting:42CrMo heat treated 50-52. 3).hydraulic system.2 sets cutting blade 4).width of cutting:600mm--1220mm. 5).the material of blade mould:Gr12MoV 6).power :22KW Motor with ZQ650 Reducer 5.slitting syste 1). The width range :200--1300mm 2). The precious of the width:±1mm 3). The speed of slitting:25m/min 4). The width can be change. 5). Material of the slitting: Cr12MoV. Hardness of slitting blade:HRC5860. 6).slitting:2~3mm 6 lines. 7).quantity of blades:10 sets . 8).Width of side scrap:3-15mm 9).The precious of side scrap:±0.5mm 10).Quantity of side scrap:2 strips 11).Slitting burr: 12).Power of the slitting:37KW,1000r/min,with ZQ750 Reducer. 6. Control System 1). Screen:3.2inch button screen 2). PLC:Delta 7. Electrical collecting machine with car 1). Material inner : 550-650mm 2). Max Coil width:1500mm 3). Carrying capacity:5T 4). Automatic relax or collect 5). Power:22KW More pictures about the slitting line:
2). The Max width:1250mm
3). The capacity :15T
