FX1200 Steel Sheet Panel Roll Making Machine

Hebei Feixiang Roll Forming Machinery Co,.Ltd
FX1200 Steel Sheet Panel Roll Making Machine thumbnail-1
FX1200 Steel Sheet Panel Roll Making Machine thumbnail-2
FX1200 Steel Sheet Panel Roll Making Machine thumbnail-3
FX1200 Steel Sheet Panel Roll Making Machine thumbnail-4
FX1200 Steel Sheet Panel Roll Making Machine thumbnail-5
FX1200 Steel Sheet Panel Roll Making Machine thumbnail-6
FX1200 Steel Sheet Panel Roll Making Machine photo-1
FX1200 Steel Sheet Panel Roll Making Machine photo-2
FX1200 Steel Sheet Panel Roll Making Machine photo-3
FX1200 Steel Sheet Panel Roll Making Machine photo-4
FX1200 Steel Sheet Panel Roll Making Machine photo-5
FX1200 Steel Sheet Panel Roll Making Machine photo-6
Negotiable MOQ: 1 Bag (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1996
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us

                         FX1200 Steel sheet panel roll making machine

Main product :

  •  Roof roll forming machine
  •  Roller shutter door roll forming machine
  •  C and Z purlin roll forming machine
  •  Downpipe roll forming machine
  •  Light keel roll forming machine
  • Guardrail roll forming machine
  • Storage roll forming machine
  • Cable tray roll forming machine
  •  Shearing machine
  •  Hydraulic decoiler
  •  Bending machine
  •  slitting machine
Features:

sheet panel roll making machine

• Easy operate with high production capacity
• Carriage with hardened gear or chain
• Magnetic linear encoder for direct measuring
• Precision length and width control
• Motor brake for secure positioning

FX1200 Steel sheet panel roll making machine


1.Working flow chart :

Manual decoiler→ Feeding material into machine→Roll forming machine→Measure  length→Hydraulic cutting→Finished Products

FX1200 Steel sheet panel roll making machine


2.Components

color steel sheet roll foming machine

a.What the main forming machine will be???→as below

FX1200 Steel sheet panel roll making machine

b.How to cut to shape??→By hydraulic

Hydraulic system

Type of cutting

Hydraulic

Cutting motion

stop cutting

Cutting tolerance

±1mm

Cutter

Cr12

Cutter quantity

1 set

Working pressure

15-20MPA

Hydraulic oil

46#

Hydraulic oil weight

50-100KGS

Hydraulic power

3kw

Cutting length

As required

No distorting or wasting. High level safety factor.

 pump

c.Can we cut to length and set quantity??→PLC control can do it!

Control Device

control

By PLC

PLC language

English and Chinese (or as required)

Brand

Delta from Taiwan

PLC screen

Touch screen or text screen

Coder

ENC-1-1-1T-24 from South Korea

Function

Automatic length and quantity measurement,


FX1200 Steel sheet panel roll making machine
d.How can we guarantee your smooth use?? →Strict quality test!
FX1200 Steel sheet panel roll making machine

Packaging & Shipping

1 .Main forming machine and un-coiler is naked.

2 .Tighten to container with steel wirerope and welded machine with container by angel iron.

3 .PLC system and motor can be packed in waterproof plastic coverage if needed and necessary.

FX1200 Steel sheet panel roll making machine


Company Information

HeBei Feixiang Roll Forming Machinery Co.,Ltd

a. Two decades professional cold steel forming equipments manufacturer

b. One comapny with two factory,about 30000 square meter,more than 100 employees

c. National GB/T,CE,ISO9001:2008 Certificates

d. Built business relationship with customers from more than 65 countries and areas

workshop

FX1200 Steel sheet panel roll making machine

FX1200 Steel sheet panel roll making machine


After-Sale Service

1). Our engineer are available service oversea in warranty period

2). Out of warranty period we also keep providing technical support online

FX1200 Steel sheet panel roll making machine


Related machines

Slitting machine

FX1200 Steel sheet panel roll making machine
