2.2kw DC-DC Converter With Canbus Communication for Passenger Vehicle

2.2kw DC-DC Converter With Canbus Communication for Passenger Vehicle thumbnail-1
2.2kw DC-DC Converter With Canbus Communication for Passenger Vehicle photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
GW
Model Number:
ED-022-336-012-01
Contact Supplier Request Quote Chat Now
Dezhou Greatway Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name GW
Model Number ED-022-336-012-01
Output Power Other, 2.2KW
Output Type Single
Size 120mm*220mm*40mm
Weight 2kg
Input Voltage 200v-420v
Output Voltage 13.7V
Type DC/DC Converters
Output Current 160a



 2.2kw DC-DC converter with Canbus Communication for passenger vehicle

















2.2kw DC-DC converter with Canbus Communication for passenger vehicle





2.2kw DC-DC converter with Canbus Communication for passenger vehicle







2.2kw DC-DC converter with Canbus Communication for passenger vehicle











Applicable for all kinds of EV, PHEV, etc







Efficiency: 96%







Cooling system: air cool







Waterproof level: IP55







Reliable technology







Anticorrosive, damp proof and moisture proof







Input over voltage, under voltage, output over current and short circuit protection


1Output power2.2KW



2Input voltage rangeDC 200V~420V



3Output current160A



4Rated output voltage13.7±0.3V



5Output power2.2KW/peak 2.5KW



6Input over voltage420V, can recover



7Input under voltage180V, can recover



8Input anti reverse connectionyes



9Output over voltage16V±0.2V, restart



10Output over current180A±5A,can recover



11Over temperatureprotect and can recover



12Impulse current13A



13Voltage adjustment≤1%



14Load adjustment≤±1.8%



15Efficiency at rated power≥92%



16Peak ripple value≤500mv



17Voltage control accuracy<1%



18Current control accuracy<2%



19Unit efficiency>90%



20Storage temperature-40℃~85℃



21Operation temperature,-40℃~65℃



22Relative humidity5%~95%  no condensation



23Air cool systemair cool



24IP levelIP55



25Weight<2KG



26Size120mm*220mm*40mm




 2.2kw DC-DC converter with Canbus Communication for passenger vehicle
