The high frequency inverter technology is used in the series of the DC-DC converter series, the performance and reliability of its volume, weight, energy consumption, efficiency, etc., are superior to other similar products,
Wide input voltage range (30~75V) can meet the different voltage level of electric vehicles.
Performance:
The inverter has high frequency, fast response, small volume, light weight, low energy consumption, high efficiency, energy saving and energy saving;
Wide range of resistance to voltage fluctuations, strong ability, high control accuracy;
With the whole machine over temperature, output reverse, output current and short circuit protection function, safe and reliable use;
On the low temperature, high temperature, moisture, acid, dust, vibration and strong environmental adaptability, stable and reliable;
Modular design of circuit structure, easy installation and maintenance.
Product features:
1 short circuit protection: when the output short circuit when the converter stops working, the automatic recovery after the short circuit;
2 over current protection: when the output current reaches the current value, the converter stops working;
3 overvoltage protection: when the output voltage is higher than the rated value, the converter stops working.
Technical parameters:
1 input voltage: 30~75V
2 input current: 10A (full load)
3 working frequency: 250KHz
4 output voltage: 19 + 0.2V
5 output current: 0~12A
6 maximum power: 240W
7 efficiency: typical 90%
8 voltage stability: < 1%
9 load stability: < 1%
10 insulation resistance: between input and output > 50M
Between input and shell > 50M
Between output and shell > 50M
11 weight: 0.25Kg
12 start delay: 2 seconds
13 working temperature: -30 ~+55
14 size: 116*50*35MM
15 wiring instructions:
Input part: red as the positive, black as the anode;
Output: coarse yellow for positive, black for the negative;
