48v to 24v 10a DC-DC Power Converter

Dezhou Greatway Import And Export Co., Ltd.
48v to 24v 10a DC-DC Power Converter thumbnail-1
48v to 24v 10a DC-DC Power Converter thumbnail-2
48v to 24v 10a DC-DC Power Converter thumbnail-3
48v to 24v 10a DC-DC Power Converter thumbnail-4
48v to 24v 10a DC-DC Power Converter photo-1
48v to 24v 10a DC-DC Power Converter photo-2
48v to 24v 10a DC-DC Power Converter photo-3
48v to 24v 10a DC-DC Power Converter photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
gw
Model Number:
DCNI
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name gw
Model Number DCNI
Output Power Other, 240w
Output Type Other, single and dual
Size 54.5*32 *90mm
Weight 0.7kg
Input Voltage 30~60V
Output Voltage 24v
Type DC/DC Converters
Output Current 10A



Unisolated DC-DC Converter

No isolation DC-DC Converter

Converter

Converters

Isolated dc to dc converter

Isolation converter

Car converter

Electric vehicle converter







The high frequency inverter technology is used in the series of the DC-DC converter series, the performance and reliability of its volume, weight, energy consumption, efficiency, etc., are superior to other similar products,
Wide input voltage range (30~60V) can meet the different voltage level of electric vehicles.
Performance:
The inverter has high frequency, fast response, small volume, light weight, low energy consumption, high efficiency, energy saving and energy saving;
Wide range of resistance to voltage fluctuations, strong ability, high control accuracy;
With the whole machine over temperature, output reverse, output current and short circuit protection function, safe and reliable use;
On the low temperature, high temperature, moisture, acid, dust, vibration and strong environmental adaptability, stable and reliable;
Modular design of circuit structure, easy installation and maintenance.
Product features:
1 short circuit protection: when the output short circuit when the converter stops working, the automatic recovery after the short circuit;
2 over current protection: when the output current reaches the current value, the converter stops working;
3 overvoltage protection: when the output voltage is higher than the rated value, the converter stops working.
Technical parameters:
1 input voltage: 30~60V
2 input current: 10A (full load)
3 working frequency: 250KHz
4 output voltage: 24 + 0.2V
5 output current: 0~10A
6 maximum power: 240W
7 efficiency: typical 90%
8 voltage stability: < 1%
9 load stability: < 1%
10 insulation resistance: between input and output > 50M
Between input and shell > 50M
Between output and shell > 50M
11 weight: 0.25Kg
12 start delay: 2 seconds
13 working temperature: -30 ~+55
14 size: 116*50*35MM
15 wiring instructions:
Input part: red as the positive, black as the anode;
Output section: coarse yellow (blue) for the positive, black as the anode













48v to 24v 10a DC-DC power converter
