300w Isolated Dc-dc Converter 48v/60v72v/84v/96 to 12v 25a

Dezhou Greatway Import And Export Co., Ltd.
300w Isolated Dc-dc Converter 48v/60v72v/84v/96 to 12v 25a thumbnail-1
300w Isolated Dc-dc Converter 48v/60v72v/84v/96 to 12v 25a thumbnail-2
300w Isolated Dc-dc Converter 48v/60v72v/84v/96 to 12v 25a thumbnail-3
300w Isolated Dc-dc Converter 48v/60v72v/84v/96 to 12v 25a thumbnail-4
300w Isolated Dc-dc Converter 48v/60v72v/84v/96 to 12v 25a thumbnail-5
300w Isolated Dc-dc Converter 48v/60v72v/84v/96 to 12v 25a photo-1
300w Isolated Dc-dc Converter 48v/60v72v/84v/96 to 12v 25a photo-2
300w Isolated Dc-dc Converter 48v/60v72v/84v/96 to 12v 25a photo-3
300w Isolated Dc-dc Converter 48v/60v72v/84v/96 to 12v 25a photo-4
300w Isolated Dc-dc Converter 48v/60v72v/84v/96 to 12v 25a photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
GW
Model Number:
PXG-300W
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name GW
Model Number PXG-300W
Output Power Other, 300w
Output Type Other, single or dual
Size 21*16*8CM
Weight 1.6kg
Input Voltage 36V-90V
Output Voltage 27V
Type DC/DC Converters
Output Current 25a



 300w isolated dc-dc converter 48v/60v72v/84v/96 to 12v 25a

 300w isolated dc-dc converter 48v/60v72v/84v/96 to 12v 25a300w isolated dc-dc converter 48v/60v72v/84v/96 to 12v 25a300w isolated dc-dc converter 48v/60v72v/84v/96 to 12v 25a





















300w isolated dc-dc converter 48v/60v72v/84v/96 to 12v 25a







300w isolated dc-dc converter 48v/60v72v/84v/96 to 12v 25a





 series isolation type DC converter is designed for headlights and audio system electricity power supply on electric vehicles ,electric froklifts,electric golf vehicles and electric touring vehicles etc.



Features



Adopt advanced power transformation technology,completely isolated power input and power output;



Built-in relay,to avoid the arc ignition when key startup and shutdown;



Perfect protection function:input under-voltage protection,output over-current protection,output short circuit protection,over temperature protection;



Small size,high efficiency,long service life,easy installation,high reliability,stable output etc.To ensure use in any vehicle and severe environment.



Specifications





Product model

SPC-300W

Electrical characteristics



Input voltage (DC/V)

36~85VDC

No-load output voltage(V)

13.8V±0.2V

Full load output voltage(V)

≥12V

Total rated output power(W)

300W@25℃

Total output current(A)

25Amax

Ripple coefficient

< 1%

Working environment temperature range(℃)

-20℃---------+60℃

Protection level

IP66

Dual output

The control line is connected with the output of 12V auxiliary output 1 and output 2

Storage environment temperature range(℃)

-30℃ ----------+70℃

Full load efficiency

> 88%

Input to output insulation resistance

Input to output insulation resistance

Seismic grade

QC/T 413 - 2002

Size

160*140*70mm







 300w isolated dc-dc converter 48v/60v72v/84v/96 to 12v 25a
