We specilize in water pump for many years, which has enjoyed great popularity in world market.This kind of high pressure water pump is designed for home use with 168F engine, which can work efficiently and stably.
Quality Control:
1: On line inspection, we perform 100% on line inspection during production not to release any problem during production.
2: 100% inspection on each finished products.
3: Customer’s own inspection.
4: Third party inspection.
5: Testing: UT, PT, MT, X-ray testing etc.
6: GB/T6402-91, JB4730-2000, JB4726-2000, JB4727-2000, JB4728-2000 and JB/T5000.8-1998.
Specifications of 1.5 Inch High Lift Water Pump
| Item | HP40A |
| Inlet Size(mm) | 40 |
| Outlet Size(mm) | 40 |
| Speed(rpm) | 3600 |
Displacement Q.max(m3 /h) | 12 |
Lift H.max(m) | 50 |
| Suction(m) | 7 |
| Engine Model | 168F |
| No. | Name | Number |
| 1 | water pump cover | 1 |
| 2 | Nut M14 | 1 |
| 3 | Bolt M6×25 | 4 |
| 4 | GB5787 | 1 |
| 5 | Pump sealing ring | 1 |
| 6 | mechanical seal/ceramic | 1 |
| 7 | Impeller | 1 |
| 8 | Eddy shell | 1 |
| 9 | Eddy shell sealing ring | 1 |
| 10 | water pump body | 1 |
| 11 | Outlet gasket | 1 |
| 12 | The water outlet joint | 8 |
| 13 | Bolt M6 | 6 |
| 14 | Bolt M6×55 | 2 |
| 15 | Threaded plug pump | 1 |
| 16 | Inlet sealing gasket | 1 |
| 17 | Inlet joint | 2 |
| 18 | Pipe joint sealing gasket | 2 |
| 19 | Pipe joint connecting nut | 2 |
| 20 | Clamp | 3 |
| 21 | filter cover | 1 |
| 22 | The handle | 1 |
| 23 | Connecting flange | 1 |
Certificate of Tianzhiyuan Water Pump
Our Service
Chongqing Tianzhiyuan Machinery Co.,Ltd. is a professional manufacturer of water pumps in China and we will provide 24 hours services for customer. If you have any needs or technque question, you can choose by online talk or call us directly.
FAQ
1.What’s your MOQ?
The sample order is OK.
2.What’s your payment terms?
T/T,L/C,D/A,D/P,etc.
3.What is the delivery time?
Standard sample 1 day.
