Smart Vortex Flowmeter

Name: Smart Vortex Flowmeter
Brand: LGDC
SKU: 141944990
Availability: InStock

Xian Wellwork Industrial Co., Ltd.

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

LGDC

Model Number:

LGDC-40/65/80/200/300/

Payment & Shipping

Payment Methods:

Port of Shipment:

xi'an

Delivery Detail:

Delivery time depends on order quantity.

Brand Name LGDC

Model Number LGDC-40/65/80/200/300/

Specifications

1. electromagnetic flowmeter
2.DN40 Flange Connection
3.SS316 Electrode
4.Caborn Case Material

Item	Compact type			Remote type
	Flange connection	Inserted type	Threaded connection	Flange connection	Inserted type	Threaded connection
Caliber(mm)	15~3000	125~3000	10~25	15~3000	125~3000	10~25
Pressure(MPa)	0.6,1.0,1.6,4.0
Accuracy	±0.5%, ±0.3%(±0.2% available for special order)
Applicable medium	Conductive liquid and slurry
Medium Temperature	≤150°C
Medium Conductivity	≥5μS/cm
Medium Velocity	≤15 m/s
Ambient	Temperature:-25°C~+60°C, Humidity: 5%~90%
Liner Material	DN10mm~32mm: Polytetrafluoroethylene(F4), Polyurethane; DN40mm~1000mm: F4, Polyurethane, Polychloropree rubber; DN1000mm~3000mm: Polychloropree rubber; Others: Polyvinyl fluoride, Fluorinated ethylene-propylene(FEP), etc.
Electrode Material	Mo-containing stainless steel, Hastelloy B, Hastelloy C, Titanium alloy, Tantalum alloy, Platinum-iridium alloy, Stainless steel-coated tungsten carbide
Electrode Type	Fixed type(DN150~DN2600); Blade type(DN300~DN1600)
Flange Material	SS, CS
Communication	RS485, RS232, HART, Profibus-DP
Signal Output	Analog 4-20mA, isolated, load resistor≤750Ω
Power Supply	AC 85-265V, 45-63Hz, power≤20W; DC 11-40V; lithium battery(3.6V)			AC 85-265V, 45-63Hz, power≤20W; DC 11-40V
Display	LCD display with back light.			Intelligent flow totalizer display.
Protection Grade	IP65			IP65, IP67, IP68
Explosion- proof Grade	Exdm II CT4, md II BT4			non
