Specifications
Cat6 Shielded RJ45 Plug1.8 pin x 8 conductor
2.3-50U gold-plated contacts
3.For Solid and Stranded cable
Cat6 Shielded RJ45 Plug for Solid and Stranded CAT6 Cable
- Allows you to create custom lengths of Patch cable by buying in bulk and terminating on your own
- 50 micron gold contacts ensure consistent data transfer
- Made with high-impact polycarbonate to withstand wear and tear
- Accepts solid or stranded cable for use in a variety of applications
When pre-terminated patch cords of certain lengths just don’t fit your application, manual termination may be your best bet. These Cat6 Shielded RJ45 Plug accept solid or stranded wire and are sturdily built, ensuring a perfect fit for your next RJ45 cable termination project.
ELECTRICAL:
UL APPLICATIONS: 250 VOLTS AC MAX, AT 2 AMPS.
DIELECTRIC WITHSTANDING VOLTAGE : 500 VOLTS AC.
INSULATION RESISTANCE: 100 MΩ
TERMINATION: RESISTANCE 20mΩ MAX AFTER
ENVIRONMENTAL TESTING.
MECHANICAL:
CABLE-TO-PLUG TENSILE STRENGTH : 20kg MIN.
DURABILITY : 200 MATING CYCLES.
MATERIAL & FINISH:
HOUSING: POLYCARBONATE, UL94V-0 OR UL94V-2.
COLOR: TRANSPARENT OR OTHER COLOR ARE AVAILABLE.
CONTACT BLADE: PHOSPHOR BRONZE.
CONDUCTOR : STRANDED & SOLID WIRE , 24AWG, 26 AWG.
GOLD PLATING: 3u''~50u",ARE AVAILABLE.
| Packing details | MOQ(PCS) | Delivery(Days) |
| 1000pcs/bag,10bags/carton | 10,000 | 7 |
Cat6 Shielded RJ45 Plug
1. Shipping Service Avaliable
2.Customer's new design Avaliable
3.OEM Service Avaliable
work products one-stop service Avaiable
Cat6 Shielded RJ45 Plug :
Cat6 Shielded RJ45 Plug :
Cat6 Shielded RJ45 Plug :
Cat6 Shielded RJ45 Plug :
