Help CenterRJ45 Modular Plugs/Connectors for Solid and Stranded Wire
Related Products
-
RJ45 Connector, Shielded RJ45 Plug for CAT 6, CAT 6A, CAT 7 Solid and Stranded CableUS$ 0.01 - 0.05MOQ: 10 Bags -
Modular Plug, RJ11 Plug, 6 Position, 4 Conductor, For Round Solid and Stranded WiresUS$ 0.003 - 0.007MOQ: 10 Bags
-
Modular Plugs, RJ12 Plug, 6 Position, 6 Conductor, For Round Solid or Stranded WireUS$ 0.003 - 0.007MOQ: 10 Bags
-
RJ45 Modular BootsUS$ 0.001 - 0.003MOQ: 10 Packs
-
Keystone Surface Mount Box, 1 Port With or Without Keystone JackUS$ 0.3 - 0.8MOQ: 500 Pieces
Specifications
RJ45 connector1.8 pin x 8 conductor
2.3-50U gold-plated contacts
3.For Solid and Stranded cable
FTP&UTP RJ45 connector for Solid and Stranded lan Cable
- Allows you to create custom lengths of Patch cable by buying in bulk and terminating on your own
- 50 micron gold contacts ensure consistent data transfer
- Made with high-impact polycarbonate to withstand wear and tear
- Accepts solid or stranded cable for use in a variety of applications
When pre-terminated patch cords of certain lengths just don’t fit your application, manual termination may be your best bet. These RJ45 connector accept solid or stranded wire and are sturdily built, ensuring a perfect fit for your next RJ45 cable termination project.
ELECTRICAL:
UL APPLICATIONS: 250 VOLTS AC MAX, AT 2 AMPS.
DIELECTRIC WITHSTANDING VOLTAGE : 500 VOLTS AC.
INSULATION RESISTANCE: 100 MΩ
TERMINATION: RESISTANCE 20mΩ MAX AFTER
ENVIRONMENTAL TESTING.
MECHANICAL:
CABLE-TO-PLUG TENSILE STRENGTH : 20kg MIN.
DURABILITY : 200 MATING CYCLES.
MATERIAL & FINISH:
HOUSING: POLYCARBONATE, UL94V-0 OR UL94V-2.
COLOR: TRANSPARENT OR OTHER COLOR ARE AVAILABLE.
CONTACT BLADE: PHOSPHOR BRONZE.
CONDUCTOR : STRANDED & SOLID WIRE , 24AWG, 26 AWG.
GOLD PLATING: 3u''~50u",ARE AVAILABLE.
| Packing details | MOQ(PCS) | Delivery(Days) |
| 1000pcs/bag,10bags/carton | 10,000 | 7 |
RJ45 Connector
1. Shipping Service Avaliable
2.Customer's new design Avaliable
3.OEM Service Avaliable
work products one-stop service Avaiable
RJ45 Connector :
RJ45 Connector :
RJ45 Connector :
RJ45 Connector :
Send Inquiry to This Supplier
