Cat5e UTP Cable
US$ 16 - 19
MOQ: 1 Roll
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Type:
Cat 5e
Number of Conductors:
8
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cat5e FTP CableUS$ 18 - 80MOQ: 1 Roll -
Category 3 External Telephone CableUS$ 0.01 - 0.99MOQ: 5 Kilometers
-
Cat3 Multipair Telephone CablesUS$ 0.01 - 0.99MOQ: 5 Kilometers
-
Mannufacturing Cat 5e FTP PatchcordsUS$ 0.1 - 10MOQ: 100 Pieces
-
Cat 5e UTP Patchcords,Cu,CCA,CCSUS$ 0.1 - 5MOQ: 100 Pieces
Place of Origin
Zhejiang, China
Type
Cat 5e
Number of Conductors
8
Specifications
24 AWG conductor solid bare copper cablePVC, LSZH and PE options
Supplied in 305m box
Printed metre marks
Category 5e UTP Cable
Category 5e Unshielded Twisted Pair (UTP) 100 Ohm cable is produced using a 4 x 2 x 24 AWG copper wire structure to a Class D standard. It supports the gigabit Ethernet protocol for horizontal and backbone installations.
Features :
24 AWG conductor – solid bare copper cable
PVC, LSZH and PE options
Supplied in 305m box
Printed metre marks
Applications :
Supports Category 5e (Class D) networks running up to 100 MHz applications
Horizontal and backbone installations
10 Base T (IEEE 802.3)
100 Base T (IEEE 802.3U)
ATM 155
100 VG any LAN (IEEE 802.12
Conformance :
Category 5e
ANSI/EIA/TIA 568B.2 : 2002
ISO/IEC 11801 : 2002
RoHS ETL/UL approved
Technical Specification
| construction | value | |
| Conductors | AWG | 24 |
| Size mm | 0.50 | |
| Material | Bare Copper | |
| Insulators | Diameter mm | 0.88+/-0.02 |
| Material | HDPE | |
| Jacket | External O.D. | 5.0 +/- 0.3 |
| Thickness mm | 0.50 +/- 0.05 | |
| Material | PVC / LSZH / PE | |
Ordering Information :
| Description | Part No |
| Cat5e Unshielded Twisted Pair (UTP) 24 AWG cable PVC 305m Box - Grey | UTP5E305PVC |
| Cat5e Unshielded Twisted Pair (UTP) 24 AWG cable LSZH 305m Box - Violet | UTP5E305LSZH |
| Cat5e Unshielded Twisted Pair (UTP) 24 AWG cable External PE - 305m box | UTP5E305EXT |
