High Quality 3-20mm Polycarbonate Solid Sheet Width of 2540mm
US$ 3 - 5
MOQ: 3000 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Lixin, OEM
Model Number:
Polycarbonate Solid Sheet
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Opal White 0.8/1mm Polycarbonate Sheet for LED Light Cover/ PC SheetUS$ 4.5 - 5MOQ: 3 Tons -
Good Apperance 0.118'' Compact Polycarbonate Sheet / Transparent RoofUS$ 3 - 4MOQ: 3 Tons
-
Good Fire Resistance Polycarbonate LED Cover Backlight HideUS$ 4.5 - 5MOQ: 3 Tons
-
High Quality Crystal Polycarbonate Solid Sheet Indoor or Outdoor Usesize /PC SheetsUS$ 4 - 40MOQ: 50 Square Meters
-
Dounble Sides Anti-scratch Polycarbonate Sheet / Hard Coating Polycarbonate SheetUS$ 4 - 6MOQ: 3 Tons
Place of Origin
China
Brand Name
Lixin, OEM
Model Number
Polycarbonate Solid Sheet
High Quality 3-20mm Polycarbonate Solid Sheet Width of 2540mm
Product Description
General solid polycarbonate sheet has the strength of light and durability, high light transmittance, execellent impact resistance, good weather resistance and simply installed. The weight is less than half of the glass. The sheets are widely used in construction and skylight, roofings decoration and so on.
Extruded out by imported production line, Gensin solid polycarbonate sheet can reach a width of 2540mm, from thickness 3mm to 20mm. Dust-free workshop insures high quality of appearance.
Application of polycarbonate solid sheet:
- Lighting
- Indoor windows and doors
- Riot windows, shop show window
- Show box, Observe window
- Awning, carport
- Indoor partition
- Advertising panel
- Soundbarrier
Features of polycarbonate sheet:
- Impact strength: the impact strength of solid PC sheets is 250 times that of glass, and the impact strength of hollow PC sheets is 80 times that of glass
- Light weight: the weight of a solid PC sheet is only about half of glass, and the weight of a hollow PC sheet is only about one twelfth at the same thickness
- Transparency: the light transmission of a 3mm solid PC sheet is 88%, and the light transmission of a 6mm hollow PC sheet is 80%
- UV-protection: a PC sheet is co-extruded with a high-density ultra violet ray that also keeps the PC sheet from discoloring
- Resistance to weather: a PC sheet has resistance to bad weather and maintains excellent properties in a wide temperature range from -40 to 120oC
- Inhibiting condensation: when the outdoor temperature is 0oC and the indoor temperature is 23oC, the PC sheet will be condensation up to 80% humidity
- Thermal insulation: the K-value of glass is 1.2 times that of solid a PC sheet and is 1.7 times that of a hollow PC sheet. PC sheets saves energy while preventing heat loss
- Sound insulation: the hollow form and polycarbonate resin offers significant advantage to that of glass
- Flame resistance: through testing by the National Center for Quality Supervision and Testing of fire building materials, the material is rated as class B1 according to QB8624-1997 standards
- Easy installation: a PC sheet can be bent while hot or cold and can be used on curved roves and windows. The minimum radius of curvature of a PC sheet is 175 times of its thickness.
Technical features of polycarbonate sheet:
- Impact strength: 850J/m
- Light transmission: 88%
- Specific gravity: 1.2 g/cm3
- Coefficient of thermal expansion: 0.065
- Temperature: -40 to 120oC
- Heat conductivity: 2.3-3.9 W/m2
- Tensile strength: >602
- Flexural strength: 1002
- Modulus of elasticity: 2,400Mpa
- Tensile street at break: >65Mpa
- Elongation at break: >100%
- Specific heat: 1.16J/kg.K
- Heat deflection temperature: 140oC
- Soundproofing: (6mm solid): 20dB
Solid Polycarbonate Sheet
Color and transmittance |
||||
Thickness |
4(mm) |
6(mm) |
8(mm) |
10(mm) |
transparent |
82% |
81% |
80% |
79% |
green |
53% |
49% |
45% |
42% |
blue |
32% |
28% |
25% |
22% |
opal |
27% |
21% |
19% |
16% |
brown |
35% |
31% |
25% |
22% |
lake blue |
57% |
525% |
48% |
47% |
| Basic Information | |
| Material | 100% Sabic/Bayer virgin material |
| UV stability | 50micron; one side or two sides |
| Guarantee | 10 years |
| Package | PE film on both sides, anti-dust tape seals the two ends |
| Delivery time | 7-10 working days against your deposit |
| Payment | 30% T/T in advance, 70% against the copy of BL |
Product Display
Brown color:
Blue color:
Company Information
Union production line:
Raw material: Sabic and Bayer material in stock.
Packaging & Shipping
Normal package: PE film on smooth side and packed on pallet.
