Dounble Sides Anti-scratch Polycarbonate Sheet / Hard Coating Polycarbonate Sheet
Gensin anti-scratch sheet not only has a sheet of polycarbonate material intrinsic properties, and also its surface with a plus one or both sides of the proprietary hard coating, provide long-lasting wear and anti-aging ability. Gensin anti-scratch sheet is safe and reliable, is the best choice of security and defense, can be used for large-scale application. This sheet can be transparent or customized colors, installation can also be used for flat-surface and curved surface.
| Item | Thickness (mm) | Standard Size (mm) |
| Anti-scratch polycarbonate sheet | 1.5-12 | 1220*2440 |
| 1830*2440 | ||
| 2000*3000 |
Features of Anti-scratch PC Sheet:
- Anti-scratch effect
- High impact strength
- Good light transmittance
- UV resistance
- Half weight of the same thickness of the glass
- 10-15 years in quality warranty
Technical Datasheet of Anti-scratch Polycarbonate Solid Sheet:
Identity |
Method |
Condition |
Unit |
Value |
Specific density |
(ISO 1183) |
|
g/m³ |
1.2 |
Absorbent |
(ISO 62) |
24h@23°C |
Mg/kg |
<8 |
Tensile strength |
(ISO 527) |
|
Mpa |
60 |
Elongation |
(ISO 527) |
|
% |
90 |
Tensile modulus of elasticity |
(ISO 527) |
|
Mpa |
2200 |
Anti-scratch test |
(ISO 179) |
Rotate 100 CS-10F,500g |
%Haze |
<1.5 |
The anti-scratch surface layer thickness |
|
|
∝m |
7-15 |
Adhesive properties |
|
0.5/1.0/2.0h Boiling 100 degrees Celsius |
|
GT 0/0/0 |
Vicat softening temperature |
(ISO 306) |
VST/B 50 |
°C |
150 |
Heat deflection temperature |
(ISO 75) |
Load:1.8MP |
°C |
135 |
Long-term temperature |
(DIN 53446) |
|
°C |
115 |
Service temperature range |
|
|
°C |
-40 - +115 |
Linear thermal expansion coefficient |
(DIN 53752) |
|
Cm/cm °C |
6.5x10^3 |
Thermal conductivity |
(DIN 52612) |
0-50°C |
W/m k |
0.21 |
Heat capacity |
|
|
J/G K |
1.3 |
LT |
(DIN 5036) |
|
% |
>86 |
Chamfer |
(DIN 52305) |
3mm |
Bg |
<5 |
Refractive ability |
(DIN 52305) |
|
dpt |
<0.1 |
Volume resistivity |
(DIN VDE0303) |
|
Ωcm |
10^15 |
Dielectric strength |
(DIN EN 60243) |
|
Kv/mm |
>30 |
Application of polycarbonate solid sheet:
- Road, elevated sound barrier
- Security lighting window
- Bullet-proof, anti-riot lighting window
- Prison window
- Industrial equipment enclosures
- Advertising light boxes and telephone booths panel
- Security shield
- Protective helmets
- Need to high impact and anti-scratch in other industrial and construction purposes
