Good Apperance 0.118'' Compact Polycarbonate Sheet / Transparent Roof
General solid polycarbonate sheet has features of high light transmittance (almost 90% for clear color) , execellent impact resistance ( 30 times of tempered glass), good weather resistance (wind&hail resistance, high snow loading capacity, unbreakable plastic) and light weight (less than half of the glass) . Polycarbonate sheets are widely used in construction and skylight, roofings decoration and so on.
| Basic Information | |
| Material | 100% Sabic/Bayer virgin material |
| UV stability | 50micron; one side or two sides |
| Guarantee | 10 years |
Colors available |
normal color: clear, opal white, blue, green, gray, brown, red, glittering colors, etc. |
| Special color: silver, opaque colors, metallic colors, diffusion colors, pearl colors, matte colors, etc | |
| Package | PE film on both sides |
| Delivery time | 7-10 working days against your deposit |
| Payment | 30% T/T in advance, 70% against the copy of BL |
| Port of loading |
Shanghai or Ningbo |
Technical datas of polycarbonate sheet:
- Impact strength: 850J/m
- Light transmission: 88%
- Specific gravity: 1.2 g/cm3
- Coefficient of thermal expansion: 0.065
- Temperature: -40 to 120oC
- Heat conductivity: 2.3-3.9 W/m2
- Tensile strength: >602
- Flexural strength: 1002
- Modulus of elasticity: 2,400Mpa
- Tensile street at break: >65Mpa
- Elongation at break: >100%
- Specific heat: 1.16J/kg.K
- Heat deflection temperature: 140oC
- Soundproofing: (6mm solid): 20dB
Application of polycarbonate sheet:
- Lighting
- Indoor windows and doors
- Riot windows, shop show window
- Show box, Observe window
- Awning, carport
- Indoor partition
- Advertising panel
- Soundbarrier
Specification of polycarbonate solid sheet:
|
Thickness (mm) |
Standard Width(mm) |
Stand Length (mm) |
Specific Gravity |
Standard Color |
| 0.8 | ||||
| 1 | ||||
| 1.5 | ||||
| 1.8 | ||||
| 2 | clear | |||
| 2.5 | green | |||
| 3 | 1200-2100 | 6000 | 1.2kg/m² | blue |
| 4 | grey | |||
| 5 | brown | |||
| 6 | opal | |||
| 7 | ||||
| 8 | ||||
| 10 | ||||
| 12 |
Solid Polycarbonate Sheet
Color and transmittance |
||||
Thickness |
4(mm) |
6(mm) |
8(mm) |
10(mm) |
transparent |
82% |
81% |
80% |
79% |
green |
53% |
49% |
45% |
42% |
blue |
32% |
28% |
25% |
22% |
opal |
27% |
21% |
19% |
16% |
brown |
35% |
31% |
25% |
22% |
lake blue |
57% |
525% |
48% |
47% |
The following is a project for an Antiques market. The whole building is used Gensin polycarbonate solid sheet.
Gensin has three production lines for polycarbonate solid sheet, one is imported extruder from Italy.
